• Model NO.：EVDC-EYU 2X70MM2+25MM2+2X4MM2+(2X0.75MM2)(P2)+10X0
• Wire Core Material：Oxygen Free Copper
• Certification：RoHS, CQC
• Model：Evdc-Eyu 2X70mm2+25mm2+2X4mm2+(2X0.75mm2)(P2)+10X0
• Brand：Zhongli
• Transport Package：Drum
• Specification：10~240mm²
• Trademark：ZHONGLI
• Origin：China

Basic Info.

Model NO. EVDC-EYU 2X70MM2+25MM2+2X4MM2+(2X0.75MM2)(P2)+10X0 Wire Core Material Oxygen Free Copper Certification RoHS, CQC Model Evdc-Eyu 2X70mm2+25mm2+2X4mm2+(2X0.75mm2)(P2)+10X0 Brand Zhongli Transport Package Drum Specification 10~240mm² Trademark ZHONGLI Origin China

Product Description

Voltage level: 1000V DC
Product specification: 10 ~ 240mm
Number of cores of main cable: 2 cores
Number of signal cores: 1 ~ 15 cores
Conductor material: oxygen free copper
Insulation material: radiation crosslinking material
Sheath material: polyurethane material
Certification: CQC certification

Purpose: This product is used for electric vehicle charging equipment and charging port, or vehicle charging and discharging warning control system with control signal transmission function of charging saturation and safety warning

Characteristics: charging pile cable is a special cable used for charging pile equipment. According to the situation of charging pile cable in the use process, the charging pile cable should have bending resistance, good power transmission performance, excellent high and low temperature resistance, oil resistance, acid and alkali resistance, water resistance, wear resistance, cracking resistance, UV resistance, flame retardant performance and other environmental performance, and all materials should meet the RoHS & reach new ring Guarantee the standard.
