100m Pass Fluke Test UTP Network LAN Cable Cat5e
Hangzhou Xingfa Technology Co., Ltd.- Conductor Type:Solid
- Application:Internet
Base Info
- Model NO.:UTP Cat5e
- Conductor Material:Copper
- Sheath Material:PVC
- Insulation Material:PE
- Material Shape:Round Wire
- Range of Application:Network
- Certification:ISO9001, CE, UL, RoHS
- Brand:Xingfa or OEM
- Center Conductor:24 AWG Bc,CCA
- Dielectric:0.90mm PE
- Insulation:Solid PE Insulation
- Jacket:5.20mm PVC
- Nom. Thick:0.55mm
- Temperature Rating:20 to 60c
- Dielectric Breakdown:2500V
- Characteristics Impedance:100&Omega
- Color:Grey, Blue, Black, Yellow, Red etc
- Delivery Time:15days
- Transport Package:Wood Reel and Carton
- Specification:24AWG+PE+AL FOIL+GROUND WIRE+5.9PVC
- Trademark:XINGFA
- Origin:Hangzhou
- HS Code:854491100
- Production Capacity:18000kilometer,Month
- Package size per unit product:35.00cm * 35.00cm * 20.00cm
- Gross weight per unit product:12.000kg
Description
Design
Product Description
Application:
Horizontal Wiring in LAN CABLE
Reference Standard
ISO/IEC 11801
TIA/EIA568B
Performance
Multi-construction
Frequency RL Attenuation NEXT ACR 4 Pairs (8 Cores)
(MHz) (dB) (dB/100m)
min. max (dB) (dB) Cable Construction
1 20.0 2.02 74.30 72.28 Conductor Solid Bare Copper
4 23.0 3.78 65.27 61.49 AWG 23
8 24.5 5.32 60.75 55.43 Conductor Dia. 0.565±0.005mm
10 25.0 5.95 59.30 53.35
16 25.0 7.55 56.24 48.68 Insulation Solid PE
20 25.0 8.47 54.78 46.31 Thickness AVG: 0.225mm, MIN: 0.22mm
25 24.3 9.51 53.33 43.83 Insulation Dia. 1.00±0.02mm
31.25 23.6 10.67 51.88 41.20 Each Pair is twisted ,Unshielded
62.5 21.5 15.38 47.36 31.98
100 20.1 19.80 44.30 24.50 Polyester NO
250 17.3 32.84 38.33 5.48 Filler Yes
Frequency ELFEXT PSNEXT PSELFEXT Impedance AL/Pet NO
(MHz) (dB) (dB) (dB/100m) (Ohm) Drain Wire NO
1 67.80 72.30 64.80
Rip Cord Yes
4 55.76 63.27 52.76
8 49.74 58.75 46.74
Jacket PVC
10 47.80 57.30 44.80
Thickness AVG: 0.52mm, MIN: 0.46mm
16 43.72 54.24 40.72 100±15 Outer Dia. 6.1±0.30mm
20 41.78 52.78 38.78
Jacket Color
25 39.84 51.33 36.84
31.25 37.90 49.88 34.90
Color
62.5 31.88 45.36 28.88
Insulation color are:
100 27.80 42.30 24.80
Blue, White/Blue
250 19.80 36.30 16.80
Orange,White/Orange
Characteristics
Green, White/Green
Max.Conductor DC Resistance at 20ºC(Ω/Km)
<93.8 Brown, White/Brown
Rated Temperature(ºC)
75
Rated Voltage(V) 300V
Marking
Velocity ratio
65% According to customer
Cable photos
Cable description
CAT6 UTP CABLE:
Category 6 (Cat6) is a "twisted pair" network cable used for carrying data signals at speeds of up to 550MHz of Bandwidth. This cable is preferred for more advanced networking installations where a higher bandwidth than normal is required.
PVC Jacket
Our Cat6 Solid Bulk Cable comes wrapped in a sturdy PVC (Polyvinyl Chloride) Jacket, built to withstand high levels of stress, pulling, and pushing.
UTP (unshielded twisted pair)
This type of cable comes with 4 Unshielded Twisted Pairs (UTP), if your installation calls for a type of cable that can withstand electrical interference and prevent signal loss.
Solid Cable Design
Designed for more straight-forward, simple installations, this particular style of Solid cable is perfect for most installations where cable runs do not require several bends and twists in the line. If you're looking for a type of cable that does require a more flexible design.
23 AWG
For this particular cable, the gauge is 23 AWG, which is a diameter of about 0.0226 Inches, or 0.573mm. 23AWG is the Industry Standard for any typical network cable installation. American Wire Gauge (AWG) is the standardized gauging system for measuring wire sizes.
Pull-Through Design
Since bulk cable is generally used in intervals, the box that it comes in is almost as important as the cable itself. This is the reason why our boxes are reinforced to provide excellent protection and are made with a simple pull-through design to keep your bulk cable free of kinks and knots while being pulled from the box.
FEATURES
· Connecting between Ethernet and network device
· CCA - Copper Clad Aluminum (CCA)
· Can be used to make smaller Cat5e cables
· Comes in an easy pull box
· Meets or exceeds Cat5e specifications
· 4 Pair Solid twisted Wires
· 23AWG
· Length: 1000ft(305m)
· 550Mhz speed
· Foot-marked cable
· Color: Black
