Manufacture Good Performance Best Price High Temperature Coaxial Cable Rg400 Military Standard Cable Coaxial for Communication
Jiangsu Elesun Cable Co., Ltd.- Conductor Material：Sc, Sccs
- Cover Material：FEP
Base Info
- Model NO.：RG400
- Type：Rg400
- Material Shape：Round Wire
- Conductor Type：Stranded
- Wire Core Material：Sccs
- Certification：CE, ISO, RoHS, CCC, UL
- Model：Rg400
- Brand：Elesun
- Material of Inner Conductor：Silver Copper
- Structure of Inner Conductor：19,0.20mm
- Material of Insulation：PTFE
- Diameter of Insulation：3.00mm
- Material of Braiding(Shielding)：Silver Copper
- Structure of Braiding(Shielding)：144+168*0.15mm
- Material of Jacket：FEP
- Diameter of Jacket：4.95mm
- Working Temp：-55ºC,200ºC
- Impedance：50Ω±2
- Voltage：3000V
- Transport Package：1000m,Reel,CTN
- Specification：29*29*26cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544200000
- Production Capacity：10000m,Day
- Package size per unit product：29.00cm * 29.00cm * 26.00cm
- Gross weight per unit product：10.000kg
Description
RG400/U coaxial cable specificationsMaterial of Inner Conductor Silver Copper Structure of Inner Conductor 19/0.20mm Material of Insulation PTFE Diameter of Insulation 3.00mm Material of Braiding(Shielding) Silver Copper Structure of Braiding(Shielding) 144+168*0.15mm Material of Jacket FEP Diameter of Jacket 4.95mm Working temp -55ºC/200ºC Impedance 50Ω±2 Voltage 3000V
