Flexible Copper/CCA Rubber Insulation Electric Welding Cable
Henan Jinshui Cable Group Co., Ltd.- Application：Construction, Overhead, Industrial
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：Rubber
- Sheath Material：Rubber
- Material Shape：Round Wire
Base Info
- Wire Core Material：Red Copper Wire
- Certification：ISO, CCC, CE
- Brand：Jinshui
- Transport Package：Reel, Drum
- Specification：CE, SGS, CCC, ISO
- Trademark：JINHSUI CABLE
- Origin：Zhengzhou Henan
- Production Capacity：1000km per month
Description
Model
Name
Main applications
Working temperature
of core ≤0C
YH
Natural Rubber Sheath for Welding Cable
Always used indoor
65
YHF
Neoprene Rubber Sheath Welding Cable
Always used outdoor
65
Synthetic elastomer Sheath Welding Cable
3th. Standards: IEC60245
4th. Specifications, Size, Weight and Technical Data
Conductor Nominal Section (mm2)
Conductive Core
Thickness of Section Sheath (mm)
Average Outer Diameter (mm2)
20oC Conductor Resistance≤(Ω/km)
Reference Weight(kg/km)
Number/Diameter of Core(mm)
Min
Max
YH
YHF
10
322/0.20
1.8
7.5
9.7
1.91
146
153.51
16
513/0.20
2.0
9.2
11.5
1.16
218.9
230.44
25
798/0.20
2.0
10.5
13.0
0.758
316.6
331.15
35
1121/0.20
2.0
11.5
14.5
0.536
426
439.87
50
1596/0.20
2.2
13.5
17.0
0.379
592.47
610.55
70
2214/0.20
2.4
15.0
19.5
0.268
790
817.52
95
2997/0.20
2.6
17.0
22.0
0.198
1066.17
1102.97
120
1702/0.30
2.8
19.0
24.0
0.161
1348.25
1392.55
150
2135/0.30
3.0
21.0
27.0
0.129
1678.5
1698.72
185
1443/0.40
3.2
22.0
29.0
0.106
1983.8
2020.74
