Class 180 Nylon/Polyurethane Enamelled Copper Wire (UEW/N 180)
Ningbo Jintian New Material Co., Ltd.- Insulation Level：H, F, B
- Certification：ISO9001, UL, RoHS
- Brand：Jintian
- Application：Transformer, Motor, Heating
- Shape：Round Wire
- Conductor Material：Copper Wire
Base Info
- Model NO.：UEW,N 180 enameled copper wire
- Size：0.04-1.80
- Thermal：180
- Type：Insulated
- Conductor Type：Solid
- Insulation Material：Enameled
- Material Shape：Round Wire
- Sheath Material：Enameled
- Range of Application：Motor and Transformers
- Transport Package：STANDARD EXPORT PACKAGE WITH WOODEN PALLETS
- Specification：IEC 60317-51; MW 83-C
- Trademark：JINTIAN
- Origin：NINGBO CHINA
- HS Code：85441100
- Production Capacity：130, 000 Tons,Year
Description
Basic Info.
Model NO. UEW/N 180 enameled copper wire Size 0.04-1.80 Thermal 180 Type Insulated Conductor Type Solid Insulation Material Enameled Material Shape Round Wire Sheath Material Enameled Range of Application Motor and Transformers Transport Package STANDARD EXPORT PACKAGE WITH WOODEN PALLETS Specification IEC 60317-51; MW 83-C Trademark JINTIAN Origin NINGBO CHINA HS Code 85441100 Production Capacity 130, 000 Tons/YearProduct Description
-Can be soldered without removal of coating, and easy to be dyed-Small dielectric loss under high frequency apparatus and good pinhole test performance
-Apply to relays, micro-motors, transformers, instrumentation and various kinds of electronic cpmponents and with for coils
With nearly 25 years of development and dedication, we are pride in the following achievements:
Production carapacity:
Annual output: 130, 000 metric tons
Product size range: 0.04mm-4.00mm
Product types: Class 130-class 240
Executive standards: IEC, JIS, DIN and NEMA
Management Systems:
ISO 9001: 2008
ISO TS 16949
ISO 14001: 2004
