Electrical Flexible Rubber Welding Machine Wire Cable for Sale 50/70/95/120/150mm2 Aluminum Copper for Industrial Leads Cord Price
Hebei Huatong Wires & Cables Group Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Underground, Industrial, Mining
- Conductor Material：Copper
- Sheath Material：Rubber, CPE, Cr, Pcp
- Insulation Material：Rubber
Base Info
- Model NO.：welding Cable H01N2-D H01N2-E
- Material Shape：Round Wire
- Range of Application：Mine
- Certification：ISO9001, UL, CCC, RoHS
- Brand：Renda
- Products Name：Welding Cable H01n2-D H01n2-E
- Ce Listed Type：Welding Cable H01n2-D H01n2-E
- Standard：IEC60245
- Rated Voltage：Low Voltage
- Insulation：Epr, EPDM, Ep
- Sheath：CPE, Sun Resistance, Oil Resistance
- Working Temperture：Max 90 Degree or 105degre
- RoHS：Yes
- Sheath Color：Black
- Resistance：Oil, Sunlight, UV
- Transport Package：Roll, Reel, Coil as Your Requirements
- Specification：10,16,25,35,50,70,95,120,185,240
- Trademark：RENDA
- Origin：China
- HS Code：8544492100
- Production Capacity：10000000FT,Month
Description
Basic Info.
Model NO. welding Cable H01N2-D H01N2-E Material Shape Round Wire Range of Application Mine Certification ISO9001, UL, CCC, RoHS Brand Renda Products Name Welding Cable H01n2-D H01n2-E Ce Listed Type Welding Cable H01n2-D H01n2-E Standard IEC60245 Rated Voltage Low Voltage Insulation Epr, EPDM, Ep Sheath CPE, Sun Resistance, Oil Resistance Working Temperture Max 90 Degree or 105degre RoHS Yes Sheath Color Black Resistance Oil, Sunlight, UV Transport Package Roll, Reel, Coil as Your Requirements Specification 10/16/25/35/50/70/95/120/185/240 Trademark RENDA Origin China HS Code 8544492100 Production Capacity 10000000FT/MonthProduct Description
H01N2-D BS EN 50525-2-81 Welding CableAPPLICATION
These cables are used as a connection to welding robots in the automotive industry, shipyards and for manually/automatically operated lines and spot welding. These cables are ideal for use as an interconnecting battery cable or in battery storage systems. The robust cable structure makes them resistant to low and high temperatures, ozone and radiation, oils, acids, fats and patrols.
STANDARDS & REFERENCES
BS EN 50525-2-81 (previously BS 638 Part 4, CENELEC HD22.6, VDE0282-6),
BS EN 60332-1-2
CONSTRUCTION
Conductor
Generally to Class 6 flexible copper conductor according to BS EN 60228 (previously BS 6360)
Separator
PET (Polyester Tape)
Sheath
The rubber compound, Type EM5 according to BS EN 50363
Technical data
Voltage Rating
100V
Temperature Rating
Fixed: -40°C to +85°C
Flexed: -20°C to +85°C
Minimum Bending Radius
Flexed: 6 x overall diameter
