Coaxial Jumper Cable LMR200 with SMA Plug for Antennas
Otto Cable Technology Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, RF Cable
- Conductor Material：BC,CCS
- Cover Material：PVC,PE,LSZH
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：LMR200
- Wire Core Material：BC,CCS
- Certification：CE, ISO, RoHS
- Model：LMR200
- Brand：Otto Cable
- Transport Package：Pallet; Coil; Carton; Spool
- Specification：4.95mm
- Trademark：OTTO CABLE
- Origin：Zhejiang, China
- HS Code：8544200000
- Production Capacity：100km,Day
Description
Basic Info.
Model NO. LMR200 Wire Core Material BC/CCS Certification CE, ISO, RoHS Model LMR200 Brand Otto Cable Transport Package Pallet; Coil; Carton; Spool Specification 4.95mm Trademark OTTO CABLE Origin Zhejiang, China HS Code 8544200000 Production Capacity 100km/DayProduct Description
Coaxial Jumper Cable LMR200 with SMA Plug for Antennas
Application:
• Mobile Antennas
• Wireless Communication Syestems
• WLL, GPS, WLAN,WiMax
• Cellphone Signal Repeaters
• Signal transmission
Features:
• 50 Ohm
• Low Loss RF Cable
• 0 - 6GHz
• Excellent performance at high frequency
• Drop-in replacement for RG58.
• REACH/RoHS compliant, CE certified.
• OEM/ODM
Assemblies:
• N, TNC, BNC, SMA......
• Customized Cable length / color/ roll size/ packing
• Various colors of Heat shrinkable tube
Construction
| Item | Material | Diameter(mm) |
| Inner Conductor Dielectric First Shield Second Shield Jacket | Bare Copper / Copper Clad Steel Foam PE Bonded Aluminum Foil Tinned Copper Wire Braid PVC/PE/LSZH | 1.12 2.95 3.07 3.66 4.95 |
Electrical Characteristics
| Impedance (Ω) Capacitance (pF/m) Velocity of Propagation (%) Return Loss Screening Effectiveness(dB) VSWR Installation Temp(ºC) Operating Temp(ºC) | 50±3 83.3 83 ≥20 ≥90 ≤1.2 -25 to +70 -25 to +70 |
Attenuation (@20ºC)
| Frequency(MHz) | Max Attenuation(dB/100m) |
| 150 220 450 900 1500 1800 2000 2500 | 14.1 16.9 23.8 33.6 43.4 48.0 51.0 57.6 |
