2c 1.5mm 180 Minutes Fire Rated Fire Rated Cable Apply for Fire Alarm System
Shenzhen Lilutong Technology Industry Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground, Construction
- Conductor Material：1.5mm2 Solid Bare Copper
- Sheath Material：Lts3
- Insulation Material：Silicone Rubber
Base Info
- Model NO.：LLT-FR215
- Material Shape：Round Wire
- Range of Application：Fire-Fighting
- Certification：ISO9001, CE, CCC, RoHS, Lpcb
- Brand：Shenzhen Llt
- Lead Time：Within 15 Days
- Insulation Color Code：1.Brn2.Blue
- Transport Package：Coil
- Specification：2C 1.5mm2
- Trademark：LLT
- Origin：Guangdong, China
- HS Code：8544492100
- Production Capacity：500000 Km,Year
Description
Basic Info.
Model NO. LLT-FR215 Material Shape Round Wire Range of Application Fire-Fighting Certification ISO9001, CE, CCC, RoHS, Lpcb Brand Shenzhen Llt Lead Time Within 15 Days Insulation Color Code 1.Brn2.Blue Transport Package Coil Specification 2C 1.5mm2 Trademark LLT Origin Guangdong, China HS Code 8544492100 Production Capacity 500000 Km/YearProduct Description
Product description2x1.5mm2 Solid FIRE Resistant Cable
Specification
1. Temperature Rating: -40°C ~ +90°C
2. Operating Voltage: 300/500V
3. Withstand voltage test:
Between insulated conductors, AC:2000V / 5min, no breakdown
Between insulated conductor and ground wire, AC: 1000V / 5min, no breakdown
4.Maximum Resistance : 12.1 Ohms/KM at 20°C
Standard
All these cables comply to
1. Application to insulation: EN50363-1,EN50363-2-1,BS2683
2. Inner Conductor Diameter: BS EN 60228
3. Insulation: EN50363-1, EN50363-2-1,BS2683
4. Sheath: EN7655-6.1, BS EN50267-2-1, BS60754, BS2683
5. Smoke emission: EN 61034-2: 2005+A2:2020
6. Corrosive and acid gas : EN 60754-1: 2014
7. Flame propagation on a single cable : EN 60332-1-2:2004
8: Fire resistance(single cable) : BS6387 , BS EN 50200, BS 8434-2
9. Fire resistance time : PH30-PH120
Application
Fire-fighting cables are mainly used for emergency lighting, fire observation, signal sensing system, blower system, communication call system, fire pump and fire alarm system circuit cables, etc.For example: Office, School, Airport, Underground and tunnel, Railway station, Computer center, Alarm system, Traffic control system, Fire protection system
Calbe Marking:
SHENZHEN LLT FIRE RESISTANT Cable 300/500V, ...... BS6387 CWZ 2x1.5mm2+E, RH , date
Related Product
Packing & Shipping
100 Meter/Rool, 200 Meter/Wooden drum, 500 Meter/Wooden drum, Carton & Pallet
Company Information
LOOKING FORWARD TO YOUR INQUIRY!!!
