• Model NO.：UTP Cat5e
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS, UL, ETL SGS CPR
• Model：UTP Cat5e
• Brand：Risun or OEM
• Frame Retardant Level：Normal,Cm,Cmr
• Transport Package：Wooden Reel, CTN
• Specification：ETL, CE, RoHS, SGS, ISO9001
• Trademark：RISUN & OEM
• Origin：Hangzhou, China(Mainland)
• HS Code：8544491100
• Production Capacity：20000 Boxes , Month

ConstructionConductor24AWG(Solid or Strand) CU/CCA/CCSInsulationHDPE 0.90± 0.06mmCores/Pairs8/4Sheath5.20+/-0.1mm PVC (FR,RoHS,UV)/ LSOH / PE Mechanical PropertiesElongationMin. 300%Temperature Range-20 up to +75° CTensile strengthMin. 1.68Kg/mmElectrical Properties (at 20°C)Conductor ResistanceMax. 9.38 ohm/100m Resistance UnbalanceMax. 2% Insulation Resistance150 ohm/KM Mutual CapacitanceMax. 5600pF/100mCpacitance UnbalanceMax. 330pF/100mImpendance100+/-15 ohmSpark Test2000V Velocity Propagation67%

	Attenuation	RL	Next	PS Next
(MHz)	(db/100m)	(db)	(db)	(db/100m)
1MHz	2.0	20	65.3	63.5
4MHz	4.1	23	56.3	54.2
8MHz	5.8	24.5	52.4	50.5
10MHz	6.6	25	51.3	49.2
16MHz	8.2	25	49.3	47.4
20MHz	9.3	25	48.8	46.9
25MHz	10.4	24	45.3	43.4
31.25MHz	11.7	23	43.0	41.8
62.5MHz	17.0	21	39.2	37.2
100MHz	22.0	20	36.3	34.4
155MHz	28.1	19	35.5	33.6
200MHz	32.4	19	31.8	29.9
240MHz	36.0	18	30.6	28.7
300MHz	41.0	18	29.2	27
350MHz	44.9	17	28.0	25.6
