China Factories Wholesale Fiberglass Polyurethane Armor Bandage Tape

Shaanxi Ansen Medical Technology Development Co., Ltd.
  • Voltage:High Voltage Cable
  • Current:DC & AC
  • Certification:CE, RoHS
  • Model:Armor
  • Brand:Ansen
  • Usage:Cold Shrink Cable Accessories

Base Info

  • Model NO.:10 cm * 460 cm
  • Indusrial:Sheath Repair;Structural Strengthening Material
  • Width of Tape:10cm,4inch
  • Length of Tape:4.6m,15FT,3m,1.5m
  • Transport Package:Paper Carton
  • Specification:64x41x42cm
  • Trademark:Ansen,OEM
  • Origin:China
  • HS Code:3005901000
  • Production Capacity:300000bags

Description

Introduction of Armor cast
1.Armorcast Structural Material is resistant to moisture, fungus, acid, alkali, ozone, sunlight, gasoline
and high temperatures.

2.It's applied to reinforth shield and connector of cable.Mostly use in aerial, buried and manhole
applications and is Ideal for strengthening old cables, splices and auxiliary seals.
Cold Shrink Wraparound Cable Sheath Repair Kits for Low & High Voltage Cables.


 Size we can manufacture for Armor cast

Name

Model

Size

Also provide

Fiberglass armor cast

Armor tape

Armor wrap

Armor Belt

AT460

10cm x 460cm

(4inch x 5yards)(4'' x 15')

glove

AT300

10cm x 300cm

(4inch x 3.3yards) (4'' x 10')



AT150

10cm x 150cm

(4inch x 1.6yards) (4'' x 5'



Ansen can OEM your size.
How to use the Armor cast
1.Prepare the surface by cleaning and roughening the cable.
2.Put on enclosed latex gloves.
3.Put water into the packing bag, press several seconds and take out the tape. Squeeze out excess water.
4.Apply around the cable extending up to 50mm either side of the cable to ensure complete coverage.   It is important that the bandage is applied.
5.Quickly as curing begins once it is taken out of the water.
6.When wrapping, pull each layer tightly by using your hand to mould and squeeze the layers together.
7.Continue this action during and upon completion.
 Application of Armor cast

1.     Recommend for the pipeline leakage not exceeding 1/8" in diameter and pipe size 2" diameter

May be used with good results on pipe with a temperature range from -29°c to 121°c.

2.     Used on electrode holder arm to ensure the welding strength and protect the electrode holder in the car

or ship industry etc.

3.      The connection of the 10KV, 35KV single-core or three- core cold shrinkable cable connector,

also the protection of the hot shrinkage cable connector.

4.     Other occasions of repairing for the rigid purpose, such as the bars of the garden tools etc



Features of Armor cast

1. Using wet type of rubber with high resistance to sunlight as the backing material net cloth backing, easy to use,

wrap on the cable accessories or electric cable directly outside protective layer to form a high strength,

can strengthen the mechanical protection of connectors and cables.

2. Once wet, the fiber strip becomes tacky and sticks to itself

3. Compatible with coaxial, copper, fiber cables, polyethylene or lead-sheathed cable, pressurized and non-pressurized cable

4. Ideal for strengthening old cables, splices and auxiliary seals

5. Fast and easy to apply, yet hardens to a strong and maintenance-free coating

6. Resists moisture, acids, alkalis, ozone, gasoline and high temperatures.

7. Can be used on pressurized or nonpressurized cable and on either polyethylene or leadsheathed cable

Precaustions of Armor cast

1.The operator should wear gloves before touch the bandage.

2.Storage at temperature(40ºF-80ºF)

3.Shelf-life: 2 years.

Quality we promised for our Armor cast
1.  3 years valid time
2.  Trial order support
3. Replace cargo in valid time without labor broken
4.  Quality Check among material, production, before shipment
 About Us: Ansen Armor cast is the manufacturer with 14 years experience specializing in orthopedic products, pipe repair tape bandage and Electric Armor Cast Wrap Tape.
