300V Tinned Copper Conductor FEP Fluoroplastic Wire 16AWG UL1227
Dongguan Dewei Wire Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Copper
- Insulation Material：FEP
- Material Shape：Round Wire
Base Info
- Model NO.：UL1227
- Certification：ISO9001, UL, RoHS
- Brand：Dewei
- Fluoroplastic Cable：UL1227--16AWG
- Transport Package：305m,Coil, 5coils in a Box
- Specification：UL1227
- Trademark：DEWEI
- Origin：Dongguan China
- HS Code：8544492100
- Production Capacity：10000m,Day
Description
Overview
Con.of conductor. Diameter Thickness of insulator Over diameter Packing NO/mm mm mm mm mt/coils 32# 7/0.08 0.24 0.2 0.64 610 30# 7/0.1 0.25 0.2 0.65 610 28# 7/0.12 0.31 0.2 0.7 610 26# 7/0.16 0.46 0.2 0.86 610 24# 7/0.2 0.61 0.2 1.01 610 22# 19/0.15 0.76 0.2 1.16 610 20# 19/0.185 0.96 0.2 1.36 305 18# 19/0.235 1.18 0.3 1.78 305 16# 19/0.3 1.51 0.3 2.11 305 14# 19/0.37 1.86 0.3 2.46 305 12# 19/0.46 2.32 0.3 2.92 305 10# 37/0.43 3.1 0.3 3.7 305 1,All raw material we selected the high quality one.
2,Professional & Skilful workers care every details in handling the producing.
3,Quality Control Department specially responsible for quality checking in each process.
