MPO (female) -Sc Singlemode 12 Core Fiber Optic Mini Round Cable 5m
Shenzhen KOC Communication Co., Ltd.- Application:Communication
- Type:Single-mode Fiber
- Connection Structure:MPO-Sc
- Material Shape:Round Wire
- Allowed Lateral Pressure:100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength:100N<1000N
Base Info
- Model NO.:MPO-SC
- Core:Multicore
- Certification:RoHS, UL, ISO9001
- Brand:Koc
- Sheath Material:LSZH
- IEC 61754-7 Compliant:Compact Design, up to 24 Fiber Ribbon
- Cable Jacket Color:Blue,Green,Aqua,Red,Magenta,Beige
- Adapter Type:MPO
- Channel:12
- Housing Color:Aqua,Green, Beige,Yellow, Magenta
- Boot Color:Black
- Boot Type:Round, Flat
- Polishing:APC, PC
- Cable Jacket Material:PVC, LSZH, Ofnr, Ofnp, PE
- Transport Package:Single Pack
- Specification:CE, RoHS, SGS
- Trademark:KOC
- Origin:Made in Shenzhen China
- HS Code:85447000
- Production Capacity:500,Prt Month
Description
Insertion LossLow Los ≤ 0.35dB Low Los ≤ 0.35dB Standard Loss ≤ 0.7dB Standard Loss ≤ 0.5dB Return Loss ≥ 55dB ≥ 30dB Durability <0.3dB typical change,
200 matings - Operating Temperature -40 to +85 ºC -40 to +85 ºC


Note: The price range is for MPO(female)-SC Singlemode 12 core mini round cable 5m.
200 matings



Note: The price range is for MPO(female)-SC Singlemode 12 core mini round cable 5m.
