• Model NO.：FTP CAT6A
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS, CPR,ETL,SGS
• Model：F,UTP CAT6A
• Brand：Risun or OEM
• Color：as Request
• Insulation：HDPE
• Jacket：PVC or LSZH
• Drain Wire：Stranded Tinned Copper (7,0.15 mm)
• Shield：Polyester Tape+Aluminium,Polyester
• Filler：PE
• Conductor：Solid Bare Copper
• Transport Package：305m,Pull Box
• Specification：CPR,ETL,CE,SGS,RoHS,ISO9001
• Trademark：Risun or OEM
• Origin：Hangzhou, China(Mainland)
• HS Code：8544491100
• Production Capacity：20000 Boxes , Mont

F/UTP CAT6A solidConductorSolid Bare Copper AWG23InsulationHD PEFillerPEShieldAluminium foil +Polyester TapeJacket PVC or LSZHDrain WireStranded tinned copper (7/0.15 mm)Package305M/1000ft, Wooden Reel, Carton, PalletDelivery timeNormally 25 days after received the deposit.ApplicationSupport 10G Base-T, 1000 Base-T and 1000 Base-TX LANs and broadband video
applications. minimum bend radius60maximum pulling tension90Nominal weight51kg/kmTemperature characteristics(˚C)100 x 240Transport/storage0 to +50˚COperating temperature-20 to +60˚CMax. conductor DC resistance 20˚C (ohms/km)98.6Min.Insulation resistance5000MDielectric strength at 50Hz1KV/1minUnbalanced capacitance-pair to ground(max)800pF/500mPropagation Velocity(NVP)78%Characteristic impedance at 100 MHz   100Φ±15% from 1 to 100 MHz

Details Images:






Company Introduction:
Since its creation in 2007, RISUN cable has beenspecialized in manufacturing of high quality network cable, coaxial cable, telephone wire and alarm cable. Our company maintains a quality assurance system to international standard ISO9001 to meet all clients expectation. OEM service is available for customer's special projects at affordable prices.

We have entered into the market of Europe, America, Southeast Asia and Middle East. Conducting business on the basis of equality, cordiality and mutual benefits,supported by our engineering design assistance and outstanding customer service. This has led to a tradition of growth and quality achievements for RISUN.



Packing&Shipping:









































Why Choose Us:











FAQ:
Q1.ARE YOU TRADING COMPANY OR MANUFACTURER ?
A: We are factory.

Q2: HOW LONG IS YOUR DELIVERY TIME?
A: Generally it is 5-10 days if the goods are in stock. or it is 20-30 days if the goods are not in stock, it is according to quantity.

Q3: DO YOU PROVIDE SAMPLES ? IS IT FREE OR EXTRA ?
A: Yes,we welcome sample order to test and check quality. we could offer the sample for free charge but do not pay the cost of freight.
Q4. DO YOU HAVE ANY MOQ LIMIT FOR ORDER?
A: Normally, 10kms per one specification and one color.

Q5. HOW DO YOU SHIP THE GOODS AND HOW LONG DOES IT TAKE TO ARRIVE?
A: Normally by sea shipping. (sample order also available by air or courier)

Q6.HOW TO PROCEED AN ORDER FOR CABLES?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples or specification and places deposit for formal order.
Fourthly We arrange the production and shipping.

Q7.IS IT OK TO PRINT MY LOGO ON CABLES?
A: Yes. Please inform us formally before our production.

Q8: WHAT IS YOUR TERMS OF PAYMENT ?
A: Payment<=60km, 100% in advance. Payment>=60km, 30% T/T in advance ,balance before shippment.
 WELCOME TO RISUN!!!
