Free Sample Communication Cat5e CAT6 CAT6A Cat5 Cat5a Network Cable
Hangzhou Spring Electronics Co., Ltd.- Type：Bare
- Conductor Type：Solid
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：lan cable
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, CCC, RoHS
- Use：for Internet Work system
- Transport Package：Carton Box
- Specification：305m,roll
- Trademark：OEM
- Origin：Made in China
- HS Code：8544200000
- Production Capacity：2, 000, 000 Pieces,Year
Description
Construction
Conductor:
23 AWG Solid Bare Copper
Pairs:
4 Pairs
Insulation:
1.02 mm HDPE
Insulation Colors:
Blue-White/Blue,Orange-White/Orange
Green-White/Green,Brown-White/Brown
Filler:
Cross Filler
Rip Cord:
Cotton
Out Jacket:
6.4±0.2 mm PVC CM
Electrical Characteristics
Impedance
1 - 250MHz 100±15 Ohms
Insulation Resistance
>5000MΩ*KM
Dielectric strength
DC 2500V 2S
Max.Conductor DC
Resistance 20ºC
8.4 Ohms/100m
Res. unbalance (%)
Max. 2.5
Pair to Ground
Capacitance Unbalance
330 pF/100m
Transfer Impendance
Max 10 mOhms/m @100Mhz
Installation temp.
-30 - 50ºC
Operation temp.
-20 - 75ºC
