UL Listed Hightemperature Rg178 Coaxial Cable for Telecommunication

Jiangsu Elesun Cable Co., Ltd.
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：FEP

Base Info

  • Model NO.：RG178
  • Type：Rg178
  • Material Shape：Round Wire
  • Conductor Type：Stranded
  • Wire Core Material：Sccs
  • Certification：CE, ISO, RoHS, CCC, UL
  • Model：Rg178
  • Brand：Elesun
  • Material of Inner Conductor：Silver Copper
  • Structure of Inner Conductor：7,0.10mm
  • Material of Insulation：PTFE
  • Diameter of Insulation：0.84mm
  • Material of Braiding(Shielding)：Silver Copper
  • Structure of Braiding(Shielding)：48*0.10mm
  • Material of Jacket：FEP
  • Diameter of Jacket：1.80mm
  • Working Temp：-55ºC,200ºC
  • Impedance：50Ω±2
  • Voltage：2000V
  • Transport Package：1000m,Reel,CTN
  • Specification：29*29*26cm
  • Trademark：ELESUN
  • Origin：China
  • HS Code：8544200000
  • Production Capacity：10000m,Day
  • Package size per unit product：29.00cm * 29.00cm * 26.00cm
  • Gross weight per unit product：15.000kg

Description

RG178/U coaxial cable specificationsMaterial of Inner ConductorSilver CopperStructure of Inner Conductor7/0.10mmMaterial of Insulation PTFEDiameter of Insulation0.84mmMaterial of Braiding(Shielding)Silver CopperStructure of Braiding(Shielding)48*0.10mmMaterial of Jacket FEPDiameter of Jacket1.80mmWorking temp-55ºC/200ºCImpedance50Ω±2Voltage2000V
