Diameter 8mm Solid Thermocouple Rod TC wire (Type K)

Shanghai Tankii Alloy Material Co., Ltd.
  • Type：Bare
  • Conductor Type：Solid
  • Application：Heating
  • Conductor Material：Chromel Alumel
  • Sheath Material：Bare
  • Insulation Material：PVC

Base Info

  • Model NO.：K
  • Material Shape：Round Wire
  • Range of Application：Heating
  • Certification：ISO9001, RoHS
  • Brand：Tankii
  • Dia：0.1~12mm
  • Surface：Bright, oxidized
  • Conductor：Chromel Alumel
  • Grade：I,II,III
  • Transport Package：100m,spool, 200m,spool
  • Specification：0.1~12mm
  • Trademark：TANKII
  • Origin：China
  • HS Code：7505220000
  • Production Capacity：1000 Tons,Year

Description


Chemical Composition
Conductor Name
Polarity
Code
Nominal Chemical Composition /%
Ni
Cr
Si
Ni-Cr
Positive
KP
90
10
--
Ni- Si
Negative
KN
97
--
3
Working Temperature
Diameter/mm
Long time Working temperature /ºC
Short period Working temperature /ºC
0.3
700
800
0.5
800
900
0.8,1.0
900
1000
1.2,1.6
1000
1100
2.0,2.5
1100
1200
3.2
1200
1300
