- Model NO.：flat copper wire
- Material Shape：Round Wire
- Range of Application：Construction Electrical
- Certification：ISO9001, CCC, BV, Tis, TUV
- Brand：Rmjt
- Color：Red, Green, Yellow, Blue or as Your Request
- Rated Voltage：300,500V 450,750V
- Standard：BS 6500, BS 6004, BS 6360, BS En 50363, IEC 60227
- Transport Package：Packaged in Coils Each 100 Meters.
- Specification：0.5-300mm²
- Trademark：RMJT
- Origin：China
- HS Code：8544492100
- Production Capacity：1000000km Per Year
| Size of conductor | Nominal thickness of insulation mm | Mean overall diameter Upper limit mm | Approx. net weight per km kg |
| Nominal cross-sectional area mm2 | Number and diameter of wires no./mm |
| 1.0 | 1/1.13 | 0.6 | 2.8 | 14 |
| 1.5 | 1/1.38 | 0.7 | 3.3 | 20 |
| 1.5 | 7/0.50 | 0.7 | 3.4 | 20 |
| 2.5 | 1/1.78 | 0.8 | 3.9 | 33 |
| 2.5 | 7/0.67 | 0.8 | 4.2 | 34 |
| 4 | 1/2.25 | 0.8 | 4.4 | 51 |
| 4 | 7/0.85 | 0.8 | 4.8 | 51 |
| 6 | 1/2.76 | 0.8 | 4.9 | 67 |
| 6 | 7/1.04 | 0.8 | 5.4 | 71 |
| 10 | 1/3.57 | 1.0 | 6.4 | 110 |
| 10 | 7/1.35 | 1.0 | 6.8 | 120 |
| 16 | 1/4.50 | 1.0 | 7.3 | 170 |
| 16 | 7/1.70 | 1.0 | 8.0 | 180 |
| 25 | 7/2.14 | 1.2 | 9.8 | 285 |
| 35 | 19/1.53 | 1.2 | 11.0 | 380 |
| 50 | 19/1.78 | 1.4 | 13.0 | 510 |
| 70 | 19/2.14 | 1.4 | 15.0 | 715 |
| 95 | 19/2.52 | 1.6 | 17.0 | 990 |
| 120 | 37/2.03 | 1.6 | 19.0 | 1230 |
| 150 | 37/2.25 | 1.8 | 21.0 | 1510 |
| 185 | 37/2.52 | 2.0 | 23.5 | 1900 |
| 240 | 61/2.25 | 2.2 | 26.5 | 2490 |
| 300 | 61/2.52 | 2.4 | 29.5 | 3050 |
| 400 | 61/2.85 | 2.6 | 33.5 | 3900 |
| 500 | 61/3.20 | 2.8 | 37.0 | 4880 |
450/750V PVC Insulated (Non-Sheathed) Flexible Conductor General Purpose Cables to BS 6004
Single Core PVC Insulated
| Size of conductor | Nominal thickness of insulation mm | Mean overall diameter Upper limit mm | renmincable.en.made-in-china.com weight per km kg |
| Nominal cross-sectional area mm2 | Number and diameter of wires no./mm |
| 1.0 | 32/0.20 | 0.6 | 3.0 | 16 |
| 1.5 | 30/0.25 | 0.7 | 3.5 | 21 |
| 2.5 | 50/0.25 | 0.8 | 4.2 | 33 |
| 4 | 56/0.30 | 0.8 | 4.8 | 50 |
| 6 | 84/0.30 | 0.8 | 6.3 | 70 |
| 10 | 80/0.40 | 1.0 | 7.6 | 120 |
| 16 | 126/0.40 | 1.0 | 8.8 | 175 |
| 25 | 196/0.40 | 1.2 | 11.0 | 290 |
| 35 | 276/0.40 | 1.2 | 12.5 | 400 |
| 50 | 396/0.40 | 1.4 | 14.5 | 565 |
| 70 | 360/0.50 | 1.4 | 17.0 | 770 |
| 95 | 475/0.50 | 1.6 | 19.0 | 1010 |
| 120 | 608/0.50 | 1.6 | 21.0 | 1260 |
| 150 | 756/0.50 | 1.8 | 23.5 | 1580 |
| 185 | 925/0.50 | 2.0 | 26.0 | 1900 |
| 240 | 1221/0.50 | 2.2 | 29.5 | 2500 |
Reference No 6192y
Flat Twin wire BVVB
| Size of conductor | Nominal thickness of insulation mm | Nominal thickness of sheath mm | Mean overall dimensions | Approx. net weight per km kg |
| Nominal cross-sectional area mm2 | Number and diameter of wires mm | Lower limit mm | Upper limit mm |
| 1.0 | 1/1.13 | 0.6 | 0.9 | 4.0*6.2 | 4.7*7.4 | 55 |
| 1.5 | 1/1.38 | 0.7 | 0.9 | 4.4*7.0 | 5.4*8.4 | 70 |
| 2.5 | 1/1.78 | 0.8 | 1.0 | 5.2*8.4 | 6.2*9.8 | 105 |
| 4 | 7/0.85 | 0.8 | 1.0 | 5.6*9.6 | 7.2*11.5 | 150 |
| 6 | 7/1.04 | 0.8 | 1.1 | 6.4*10.5 | 8.0*13.0 | 205 |
| 10 | 7/1.35 | 1.0 | 1.2 | 7.8*13.0 | 9.6*16.0 | 325 |
| 16 | 7/1.70 | 1.0 | 1.3 | 9.0*15.5 | 11.0*18.5 | 465 |
Reference No 6242y
Flat-Twin with Bare Earth-continuity Conductor
| Size of conductor | Nominal thickness of insulation mm | Size of earth conductivity conductor no./mm | Nominal thickness of sheath mm | Mean overall dimensions | Approx. net weight per km kg |
| Nominal cross- sectional area mm2 | Number and diameter of wires mm | Lower limit mm | Upper limit mm |
| 1.0 | 1/1.13 | 0.6 | 1/1.13 | 0.9 | 4.0*7.2 | 4.7*8.6 | 70 |
| 1.5 | 1/1.38 | 0.7 | 1/1.13 | 0.9 | 4.4*8.2 | 5.4*9.6 | 85 |
| 2.5 | 1/1.78 | 0.8 | 1/1.13 | 1.0 | 5.2*9.4 | 6.2*11.0 | 120 |
| 4 | 7/0.85 | 0.8 | 1/1.38 | 1.0 | 5.6*10.5 | 7.2*13.0 | 175 |
| 6 | 7/1.04 | 0.8 | 1/1.78 | 1.1 | 6.4*12.5 | 8.0*15.0 | 240 |
| 10 | 7/1.35 | 1.0 | 7/0.85 | 1.2 | 7.8*15.5 | 9.6*19.0 | 390 |
| 16 | 7/1.70 | 1.0 | 7/1.04 | 1.3 | 9.0*18 | 11.0*22.0 | 560 |
300/300V CU/PVC/PVC Sheathed Circular Light Flexible Cords to BS 6500
Reference No 2182Y Twin Core
| Size of conductor | Nominal thickness of insulation mm | Nominal thickness of sheath mm | Mean overall dimensions | Approx. net weight per km kg |
| Nominal cross- sectional area mm2 | Number and diameter of wires No./mm | Upper Limit mm | Upper Limit mm |
| 0.5 | 16/0.20 | 0.5 | 0.6 | 4.8 | 6.0 | 36 |
| 0.75 | 24/0.20 | 0.5 | 0.6 | 5.2 | 6.4 | 45 |
CU/PVC/PVC Sheathed Circular Light Flexible Cords
Reference No 3183Y Three Core
| Size of conductor | Nominal thickness of insulation mm | Nominal thickness of sheath mm | Mean overall dimensions | Approx. net weight per km kg |
| Nominal cross- sectional area mm2 | Number and diameter of wires no/mm | Lower Limit mm | Upper Limit mm |
| 0.75 | 24/0.20 | 0.6 | 0.8 | 6.4 | 8.0 | 74 |
| 1.0 | 32/0.20 | 0.6 | 0.8 | 6.8 | 8.4 | 86 |
| 1.25 | 40/0.20 | 0.7 | 0.9 | 7.6 | 9.4 | 104 |
| 1.5 | 30/0.25 | 0.7 | 0.9 | 8.0 | 9.8 | 120 |
| 2.5 | 50/0.25 | 0.8 | 1.1 | 9.6 | 12.0 | 180 |
