Manufacture High Performance Best Price High Temperature Rg178 Coaxial Cable for Communication
Jiangsu Elesun Cable Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, RF Cable, Submarine Cable, Antenna Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：FEP
- Type：Rg178
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：RG178
- Wire Core Material：Sccs
- Certification：CE, ISO, RoHS, CCC, UL
- Model：Rg178
- Brand：Elesun
- Material of Inner Conductor：Silver Copper
- Structure of Inner Conductor：7,0.10mm
- Material of Insulation：PTFE
- Diameter of Insulation：0.84mm
- Material of Braiding(Shielding)：Silver Copper
- Structure of Braiding(Shielding)：48*0.10mm
- Material of Jacket：FEP
- Diameter of Jacket：1.80mm
- Working Temp：-55ºC,200ºC
- Impedance：50Ω±2
- Voltage：2000V
- Transport Package：1000m,Reel,CTN
- Specification：29*29*26cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544200000
- Production Capacity：10000m,Day
Description
RG178/U coaxial cable specificationsMaterial of Inner Conductor Silver Copper Structure of Inner Conductor 7/0.10mm Material of Insulation PTFE Diameter of Insulation 0.84mm Material of Braiding(Shielding) Silver Copper Structure of Braiding(Shielding) 48*0.10mm Material of Jacket FEP Diameter of Jacket 1.80mm Working temp -55ºC/200ºC Impedance 50Ω±2 Voltage 2000V
