Silicone Rubber 150 Degree UL3132 Cable Wire for Wiring Harness
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Lighting, Lamb
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PE
Base Info
- Model NO.：UL3132
- Material Shape：Flat Wire
- Range of Application：Flame Retardant
- Certification：UL, RoHS, VDE
- Brand：Bort
- Packaging：100m,Roll, 305m,Roll, 610m,Roll, Wrap Plastic Film
- Color Available：Any Colors
- Sample：Conventional Sample Free
- Delivery Time for Mass Production：7-10days
- Appliance：for Internal Wiring of Appliances
- Service：OEM, ODM
- Standard of Production：RoHS & Reach
- Factory Management Standard：ISO9001:2008
- Company Type：Manufacturer
- Producing Experience：10years
- Transport Package：Coiled in The Plastic Spool
- Specification：26-9AWG
- Trademark：BoRt
- Origin：Zhangzhou, China
- HS Code：8544492900
- Production Capacity：300000kms
Description
Overall Diameter
(mm)Nom. Min. Nom. Tol. 16 7/0.49 14.60 1.50 0.40 0.33 2.30 ±0.10 18 7/0.39 23.20 1.19 0.40 0.33 1.97 ±0.10 20 7/0.30 36.70 0.92 0.46 0.33 1.85 ±0.10 22 17/0.16 59.40 0.76 0.46 0.33 1.70 ±0.10 22 7/0.254 59.40 0.76 0.46 0.33 1.70 ±0.10 22 1/0.65 5 56.40 0.65 0.46 0.33 1.57 ±0.10 24 133/0.05 94.20 0.67 0.40 0.33 1.47 ±0.10 24 19/0.12 94.20 0.60 0.40 0.33 1.40 ±0.10 24 11/0.16 94.20 0.61 0.40 0.33 1.41 ±0.10 24 7/0.20 94.20 0.61 0.40 0.33 1.41 ±0.10 24 1/0.51 89.30 0.51 0.40 0.33 1.31 ±0.10 26 1/0.4 150.00 0.48 0.40 0.33 1.28 ±0.10 26 7/0.127 143.00 0.40 0.40 0.33 1.20 ±0.10 28 7/0.127 239.00 0.38 0.40 0.33 1.18 ±0.10 30 7/0.10 381.00 0.30 0.40 0.33 1.10 ±0.10
(mm)
