XLPE Coax Cable RG174 Dual Cable for GSM Antenna
Otto Cable Technology Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, RF Cable
- Conductor Material：BC,TC
- Cover Material：PVC
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：RG174-XLPE DUAL
- Wire Core Material：BC,TC
- Certification：CE, ISO, RoHS
- Model：RG174 XLPE Dual
- Brand：Otto Cable
- Transport Package：Pallet; Carton; Coil
- Specification：2.8mm
- Trademark：Otto Cable
- Origin：Zhejiang, China
- HS Code：8544200000
- Production Capacity：150km,Day
Description
Basic Info.
Model NO. RG174-XLPE DUAL Wire Core Material BC/TC Certification CE, ISO, RoHS Model RG174 XLPE Dual Brand Otto Cable Transport Package Pallet; Carton; Coil Specification 2.8mm Trademark Otto Cable Origin Zhejiang, China HS Code 8544200000 Production Capacity 150km/DayProduct Description
MIL-C-17 Low Loss XLPE RG 174 Dual Coaxial Cable
Construction
| Item | Material | Diameter(mm) |
| Inner Conductor Dielectric Shield Jacket | Bare Copper / Tinned Copper Solid PE / XLPE Bare Copper or Tinned Copper Wire Braid PVC | 7*0.16 1.52 1.90 2.80 |
Electrical Characteristics
| Impedance (Ω) Capacitance (pF/m) Velocity of Propagation (%) Return Loss Installation Temp(ºC) Operating Temp(ºC) | 50±3 101 66 20 -30 to +85 / 105 -30 to +85 / 105 |
Attenuation (@20ºC)
| Frequency(MHz) | Max Attenuation(dB/m) |
| 400 600 860 1000 1575 | 0.62 0.72 0.90 1.00 1.10 |
