UL20276 28AWG Lvds Display Connection 1.5mm Multicore Cable Electrical Wire
CB (XIAMEN) INDUSTRIAL CO., LTD.- Type：Insulated
- Conductor Type：Stranded
- Application：Interal Wiring of Vehicle
- Conductor Material：Copper
- Sheath Material：No
- Insulation Material：PVC
Base Info
- Model NO.：UL20276
- Material Shape：Round Wire
- Range of Application：Wiring
- Certification：ISO9001, UL, RoHS, Reach
- Brand：Bort
- Transport Package：Roll, Customization
- Specification：AWG12-30
- Trademark：Bort
- Origin：China
- HS Code：8544492900
- Production Capacity：500000km,Per Year
Description
Maximum Resistance at 20 ºC
Ω/kmAWG No./mm Nom./Dia.
mm Nom. Thick.
mm Nom.Dia.
mm Material Coverage Nom. Thick.
mm Dia.
mm 3P 26 7/0.16 0.48 0.26 1.00 - PAPER 82% 1.05 6.40 139 1C 26 7/0.16 0.48 0.26 1.00 139 3P 28 7/0.127 0.38 0.12 0.63 7/0.16 AL 95% 0.56 4.70 223 9C 28 7/0.127 0.38 0.12 0.63 223 6P 28 7/0.127 0.38 0.12 0.63 7/0.127 PET 70% 0.70 4.70 223 7P 28 7/0.127 0.38 0.12 0.63 - PAPER 90% 0.95 5.30 223 8P 28 7/0.127 0.38 0.12 0.63 7/0.127 PET 74% 0.70 5.00 223 12P 28 7/0.127 0.38 0.12 0.63 7/0.2 AL 84% 1.00 6.70 223 1C 28 7/0.127 0.38 0.12 0.63 223 13P 28 7/0.127 0.38 0.12 0.63 7/0.2 AL 85% 0.92 7.00 223 18P 28 7/0.127 0.38 0.12 0.63 - AL 80% 0.76 7.40 223 19P 30 7/0.1 0.30 0.15 0.60 7/0.127 AL 85% 1.28 8.50 354 25P 30 7/0.1 0.30 0.15 0.60 7/0.127 AL 85% 1.39 9.50 354 25P 28 7/0.127 0.38 0.12 0.63 - AL 80% 0.72 8.20 223
Ω/km
mm
mm
mm
mm
mm
