600V 4AWG Solid UL1015 UL1569 Electrical Copper Lead Wire

Jiangsu Elesun Cable Co., Ltd.
  • Wire Core Material：Tin Plated Copper Wire
  • Industry Type：Industrial Wire Harness

Base Info

  • Model NO.：UL1015
  • Bandaging Materials：PVC Pipe
  • General Wiring Harness：Crimping Assembling Classes
  • Signal：Low Voltage Wiring Harness
  • Shape：Round
  • Interface Type：DC,DC
  • Certification：RoHS, ISO9001, UL, CCC
  • Brand：Elesun
  • Material of Inner Conductor：Tinned Copper
  • No. of Inner Conductor：Solid , 19 Strands, 41 Strands
  • Material of Jacket：From 22 AWG to 1AWG
  • Rated Working Temp：-40ºC to +105ºC
  • Voltage：600V
  • Transport Package：305m,Roll
  • Specification：32.5*31*16.5cm
  • Trademark：ELESUN
  • Origin：China
  • HS Code：8544492100
  • Production Capacity：10000m,Day
  • Package size per unit product：29.00cm * 29.00cm * 26.00cm
  • Gross weight per unit product：12.000kg

Description

UL style 1015 AWM 1015 hook up wire  specificationsMaterial of Inner ConductorTinned copperNo. of Inner ConductorSolid , 19 strands, 41 strandsMaterial of JacketPVCDiameter of jacketFrom 22 awg to 1awgRated Working Temp-40ºC to +105ºCVoltage600V
Conductor structure and Resistance

AWGConductor Structure (NO.of strands)Diameter of Conductor(mm)20ºC Max Resistance (Ω/km)Min Insulation Thickness(mm)
221,7,17Ф0.64;Ф0.76;Ф0.7754.30.79
201,7,21Ф0.81;Ф0.93;Ф0.9533.90.79
181,7,16Ф1.02;Ф1.17;Ф1.21,21.40.79
1619,65Ф1.50;Ф1.49,13.50.79
1419,105Ф1.86;Ф2.15,8.450.79
1219,65Ф2.43;Ф2.36,5.310.79
1019,105Ф2.94;Ф3.41,3.360.79
819,168Ф3.75;Ф4.282.111.14
619,105Ф4.75;Ф5.421.331.14
419,168Ф6.00;Ф6.850.841.14
219,266Ф7.55;Ф8.620.531.52
119,209Ф8.45;Ф9.670.422.03
