Manufacture 2.5mm 4mm 6mm 10mm 450/750V Copper PVC Insulated Electric Wire UL1007 UL1015 for House
Jiangsu Elesun Cable Co., Ltd.- Wire Core Material：Tin Plated Copper Wire
- Industry Type：Industrial Wire Harness
Base Info
- Model NO.：UL1015
- Bandaging Materials：PVC Pipe
- General Wiring Harness：Crimping Assembling Classes
- Signal：Low Voltage Wiring Harness
- Shape：Round
- Interface Type：DC,DC
- Certification：RoHS, ISO9001, UL, CCC
- Brand：Elesun
- Material of Inner Conductor：Tinned Copper
- No. of Inner Conductor：Solid , 19 Strands, 41 Strands
- Material of Jacket：From 22 AWG to 1AWG
- Rated Working Temp：-40ºC to +105ºC
- Voltage：600V
- Transport Package：305m,Roll
- Specification：32.5*31*16.5cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544492100
- Production Capacity：10000m,Day
- Package size per unit product：29.00cm * 29.00cm * 26.00cm
- Gross weight per unit product：10.000kg
Description
UL style 1015 AWM 1015 hook up wire specificationsMaterial of Inner Conductor Tinned copper No. of Inner Conductor Solid , 19 strands, 41 strands Material of Jacket PVC Diameter of jacket From 22 awg to 1awg Rated Working Temp -40ºC to +105ºC Voltage 600V
Conductor structure and Resistance
Conductor structure and Resistance
| AWG | Conductor Structure (NO.of strands) | Diameter of Conductor(mm) | 20ºC Max Resistance (Ω/km) | Min Insulation Thickness(mm) |
| 22 | 1,7,17 | Ф0.64;Ф0.76;Ф0.77 | 54.3 | 0.79 |
| 20 | 1,7,21 | Ф0.81;Ф0.93;Ф0.95 | 33.9 | 0.79 |
| 18 | 1,7,16 | Ф1.02;Ф1.17;Ф1.21, | 21.4 | 0.79 |
| 16 | 19,65 | Ф1.50;Ф1.49, | 13.5 | 0.79 |
| 14 | 19,105 | Ф1.86;Ф2.15, | 8.45 | 0.79 |
| 12 | 19,65 | Ф2.43;Ф2.36, | 5.31 | 0.79 |
| 10 | 19,105 | Ф2.94;Ф3.41, | 3.36 | 0.79 |
| 8 | 19,168 | Ф3.75;Ф4.28 | 2.11 | 1.14 |
| 6 | 19,105 | Ф4.75;Ф5.42 | 1.33 | 1.14 |
| 4 | 19,168 | Ф6.00;Ф6.85 | 0.84 | 1.14 |
| 2 | 19,266 | Ф7.55;Ф8.62 | 0.53 | 1.52 |
| 1 | 19,209 | Ф8.45;Ф9.67 | 0.42 | 2.03 |
