• Model NO.：6XV1830-0EH10
• Material Shape：Round Wire
• Range of Application：Communication
• Certification：ISO9001, VDE
• Brand：Llt
• Transport Package：Wooden Roller, Plastic Spool.
• Specification：1*2*22 AWG,1
• Trademark：LLT
• Origin：China
• HS Code：854449
• Production Capacity：50000,Day

Basic Info.

Model NO. 6XV1830-0EH10 Material Shape Round Wire Range of Application Communication Certification ISO9001, VDE Brand Llt Transport Package Wooden Roller, Plastic Spool. Specification 1*2*22 AWG/1 Trademark LLT Origin China HS Code 854449 Production Capacity 50000/Day

Product Description

Product name:                Industrial communication communication field bus
product model :              6XV1830-0EH10 purple cable
Product category :         Profibus DP cable, Profibus PA cable, purple wire
Standard :                       QB/LLT 11116-2014
1, the application
Purple cable is mainly used in industrial bus, equipment fixed wiring, motion wiring, towing chain system, robot system, wind power system, Marine system, railway locomotive system and other fields of industrial communication occasions, can meet different application requirements, such as: underground cable, towing cable, dangerous area.

2. Product features
Double shield jacket, which is suitable for installation in the industrial environment vulnerable to electromagnetic interference;
Parameters: Single cable transmission specification :1000m, with repeater can be extended to 10000m
The cable is made of high flame retardant material, which meets high flame retardant requirements.

3. Product Description
Conductor :  0.64mm solid bare copper conductor;
Insulation: made by foaming PE leather - foaming - leather method, core wire color: red, green; Two cores are combined in a pair;
The first isolation layer: PET wrapping is adopted after core wires are paired; Middle layer sheath: made of high flame retardant material;
Shielding layer: aluminum-plastic composite tape, bare copper wire (or tinned copper wire) braided double shielding;
Outer protective layer: according to the design of different places, can choose PVC, LSZH, PUR and other bonded system, flame retardant, appearance purple (similar to RAL4001):
flame retardant performance: in line with VDE 0472 standard; Class B test (IEC332.1);
Characteristic impedance :150 Ω ±15 2~20MHZ;
Dc resistance :57.5 Ω /KM;
Working temperature :  PVC:-20ºC~105ºC PUR/LSZH :-30ºC~90ºC
