Factory Directly Sale Good Quality High Temperature PTFE Insulation RF Coaxial Cable Rg178 Rg179 Rg316 for Antenna System
Jiangsu Elesun Cable Co., Ltd.- Conductor Material：Sc
- Cover Material：FEP
Base Info
- Model NO.：RG179
- Type：Rg179
- Material Shape：Round Wire
- Conductor Type：Stranded
- Wire Core Material：Sccs
- Certification：CE, ISO, RoHS, CCC, UL
- Model：Rg179
- Brand：Elesun
- Material of Inner Conductor：Silver Copper
- Structure of Inner Conductor：7,0.10mm
- Material of Insulation：PTFE
- Diameter of Insulation：1.50mm
- Material of Braiding(Shielding)：Silver Copper
- Structure of Braiding(Shielding)：80*0.10mm
- Material of Jacket：FEP
- Diameter of Jacket：2.53mm
- Working Temp：-55ºC,200ºC
- Impedance：75Ω±3
- Voltage：1200V
- Transport Package：1000m,Reel,CTN
- Specification：29*29*26cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544200000
- Production Capacity：10000m,Day
- Package size per unit product：29.00cm * 29.00cm * 26.00cm
- Gross weight per unit product：10.000kg
Description
RG179/U coaxial cable specificationsMaterial of Inner Conductor Silver Copper Structure of Inner Conductor 7/0.10mm Material of Insulation PTFE Diameter of Insulation 1.50mm Material of Braiding(Shielding) Silver Copper Structure of Braiding(Shielding) 80*0.10mm Material of Jacket FEP Diameter of Jacket 2.53mm Working temp -55ºC/200ºC Impedance 75Ω±3 Voltage 1200V
