Manufacture UL1569 PVC Jacket Cable and Wire 300V 105c 22AWG 20AWG for Automobile
Jiangsu Elesun Cable Co., Ltd.- Wire Core Material：Tin Plated Copper Wire
- Industry Type：Industrial Wire Harness
Base Info
- Model NO.：UL1569
- Bandaging Materials：PVC Pipe
- General Wiring Harness：Crimping Assembling Classes
- Signal：Low Voltage Wiring Harness
- Shape：Round
- Interface Type：DC,DC
- Certification：RoHS, ISO9001, UL, CCC
- Brand：Elesun
- Material of Inner Conductor：Tinned Copper
- No. of Inner Conductor：Solid , 19 Strands, 41 Strands
- Material of Jacket：From 22AWG to 6 AWG
- Rated Working Temp：-40ºC to +105ºC
- Voltage：300V
- Transport Package：305m,Roll
- Specification：32.5*31*16.5cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544492100
- Production Capacity：10000m,Day
- Package size per unit product：29.00cm * 29.00cm * 26.00cm
- Gross weight per unit product：12.000kg
Description
UL style 1569 AWM 1569 hook up wire specificationsMaterial of Inner Conductor Tinned copper No. of Inner Conductor Solid , 19 strands, 41 strands Material of Jacket PVC Diameter of jacket From 22awg to 6 awg Rated Working Temp -40ºC to +105ºC Voltage 300V
Conductor structure and Resistance
Conductor structure and Resistance
| AWG | Conductor Structure (NO.of strands) | Diameter of Conductor(mm) | 20ºC Max Resistance (Ω/km) | Min Insulation Thickness(mm) |
| 22 | 1,7,11,17 | Ф0.64,Ф0.76,Ф0.77 | 54.3 | 0.38 |
| 20 | 1,7,21,26 | Ф0.81,Ф0.93,Ф0.95 | 33.9 | 0.38 |
| 18 | 1,7,16,34 | Ф1.02,Ф1.17,Ф1.21, | 21.4 | 0.38 |
| 16 | 1,7,19,26,65 | Ф1.30,Ф1.50,Ф1.49, | 13.5 | 0.38 |
