Coax Cable RF 8d-Fb Alsr600 Cable Copper 50 Ohm for Communication System
Jiangsu Elesun Cable Co., Ltd.- Conductor Material:Copper
- Cover Material:PVC Lzsh PE
Base Info
- Model NO.:8D-FB
- Type:Coaxial
- Material Shape:Round Wire
- Conductor Type:Solid
- Wire Core Material:Tinned Wire
- Certification:CE, ISO, RoHS, UL
- Brand:Elesun
- Color:White Black
- Impedance:50ohm
- Working Temperature:-20~80
- Transport Package:Pallet
- Specification:128*0.15TC
- Trademark:ELESUN
- Origin:China
- HS Code:8544200000
- Production Capacity:300km,Month
- Package size per unit product:36.00cm * 36.00cm * 28.00cm
- Gross weight per unit product:15.000kg
Description
SYWV50-8(8D-FB) foam PE insulated coaxial cable specifications
Material of Inner Conductor
BC (Bare Copper)
Structure of Inner Conductor
1/2.80mm
Material of Insulation
FPE(Foam PE)
Diameter of Insulation
7.80mm
1st Shielding
Aluminum Tape
Material of Braiding(2nd Shielding)
TC (Tinned Copper),
Structure of Braiding(2nd Shielding)
128/0.15mm
Material of Jacket
PVC, PE, LSZH,FR-LSZH
Diameter of Jacket
11.10mm
Working temp
-20ºC/70ºC
Impedance
50Ω±2
Voltage
2500V
SWR(0-2500MHz)
≤1.2
Nominal Weight(KGS/KM)
160
FAQ
Q: Can I have a sample testing before mass order?
Yes, We provide samples free and sample freight charge will be paid by customer. Sample delivery time is quick.
Q: What about the lead time of production
Usually it is 10-15days, for cables above 300KM delivery time is about 20-25 days
Q: Do you have MOQ limit for order
Normally 1KM each item, for special order less than 1KM we can check together.
Q: How about shipment way?
For samples which we choose UPS/DHL/TNT/FEDEX and for sea shipment we choose SHA or NINGBO port
Q: Is it OK to print our logo on the cable?
Yes Of course,just forward us your details before placing order.
Q: How do you solve the problem of after sale service
Quality is the priority rule in our company, we will make sure the quality before delivery and any
feedback from customer we will handle and replace asap.
