GYXTW Fiber Optic Cable Sm 2-12 F Unitube Outdoor Use

DONGGUAN TW-SCIE CO., LTD.
  • Application：Communication, Optic Cable
  • Type：Single-mode Fiber
  • Connection Structure：Optic Cable
  • Certification：RoHS, CE, ISO9001, Optic Cable
  • Product Nmae：Optic Cable
  • Installation Style：Duct & Aerial

Base Info

  • Model NO.：GYXTW
  • Brand Name of Fiber：Corning, Yofc, Draka
  • Loose Tube Material：PBT with Jerry
  • Waterblocking Material：Water Blocking Tape or Filling Compound
  • Outer Sheath Material：MDPE , HDPE ,LSZH
  • Outer Sheath Color：Black
  • Armour Material：Steel Tape
  • Color of Fiber and Loose Tube：Red, Black, Yellow, Violet, Pink, Aqua
  • Color of Fiber /Loose Tube：Blue, Orange, Green, Brown, Grey, White
  • Transport Package：Wooden Drum
  • Specification：SGS ROHS REACH ISO
  • Trademark：TW-SCIE optic cable
  • Origin：China (Mainland) Guangdong Dongguan
  • HS Code：8544700000
  • Production Capacity：200km,Day

Description

 G.652G.65550/125μm62.5/125μmAttenuation
(+20ºC)@850nm  ≤3.0 dB/km≤3.0 dB/km@1300nm  ≤1.0 dB/km≤1.0 dB/km@1310nm≤0.36 dB/km≤0.40 dB/km  @1550nm≤0.22 dB/km≤0.23dB/km  Bandwidth (Class A)@850nm  ≥500 MHz·km≥200 MHz·km@1300nm  ≥1000 MHz·km≥600 MHz·kmNumerical Aperture  0.200±0.015NA0.275±0.015NACable Cut-off Wavelength λcc≤1260nm≤1480nm  GYXTW Fiber Optic Cable Sm 2-12 F Unitube Outdoor Use GYXTW Fiber Optic Cable Sm 2-12 F Unitube Outdoor Use
Company Information

Dong Guan Tw-Scie Co., Ltd. is a high-tech enterprise group in China devoted to communications undertakings with our own impoters and exporters rights. Since its founding, high quality products an strong co-operations have enabled the enterprise to stably and rapidly grow into a specialized communication Manufacturer supplier and engineering service provider the most complete product line-up and specifications in the fiber and cable industry of China.

The enterprise is possessed of a passel of faithful, intelligent, conscientious talents. While bending ourselves to following with the worldwide advanced development and application, we build up cooperation ties with many scientific research academy.

The main products of our enterprise are:
optic cable, optical cable, Optical media converter, optical transceiver, optical coupler, optical modem, optical connector, optical distribution frame.

All of the products are widely used in telecom, electric power, railway and other related department, exporting France, India, Singapore, Malaysia.

optic cable is mostly competitive, contact us now!
