• Model NO.：overhead cable
• Certification：CCC, CE, RoHS, UL, VDE
• Model：YJV
• Brand：Rmjt
• Insulation：XLPE PVC PE
• Jacket：PVC XLPE PE
• Conductor：Aluminium
• Name：Insulated Electricsl Cable
• Transport Package：Wooden Box
• Specification：aluminum Steel acsr
• Trademark：RMjT
• Origin：Henan, China
• HS Code：8544492100
• Production Capacity：999999999km Per Year

 <sup>Product Use Characteristics
1.Rated voltage:
* 1kV, 10kV
2.Allowable working temperature of cable:
* 70 ºC for PVC insulation ;
* 90 ºC for XLPE insulation ;
* 70 ºC for PE insulation ;
* 75 ºC for HDPE insulation ;
3.When short circuit occurs (maximum time does not exceed 5 seconds), the maximum temperature of the cable:
* 160 ºC for PVC insulation ;
* 150 ºC for HDPE insulation ;
* 250 ºC for XLPE insulation ;
* 130 ºC for PE insulation ;
4.The ambient temperature for cable laying shall not be lower than -20 ºC, and the installation laying temperature shall not be lower than 0 ºC.
5.Allowable bending radius of cable:
* Cables with a rated voltage less than 1kV:Cables with an outer diameter (D) less than 25mm, not less than 4D;Cables with an outer diameter (D) of 25mm or more, not less than 6D
* 10kV rated voltage cable:Single-core cable 20 (D + d) ± 5% mm, multi-core cable 15 (D + d) ± 5 mm.</sup>

 ^{Technical Parameters Of Overhead Insulated Cable
1.Weather resistance
High electrical performance, good weather resistance, can work safely under long-term sunlight
2.Insulation level
The ground voltage of the overhead cable is shared by the main insulation and the air medium, and the insulation performance is higher, which is better than that of ordinary ordinary oil paper and cross-linked cables.
3.Inner and outer semi-conductive shielding layer
1KV low-voltage overhead cable, the surface electric field strength is very low, do not need to use the inner semi-conductive shield.When the overhead cable is close to the grounding body, the electric field strength on the surface of the conductor of the 10kV overhead cable is 2 ~ 3kV / mm, and the electric field strength on the surface of the conductor of the 35kV overhead cable can be as high as about 5kV / mm, and the inner semi-conductive shielding layer is needed.}

 ^{Application of XLPE Insulated Cable
1.Overhead insulated cables with a rated voltage of 1kV and below are suitable for overhead power lines with a rated voltage of 0.6% 2F1KV and below, and can be used as fixed laying or household wires.
2.Overhead insulated cables with a rated voltage of 10kV and below are suitable for overhead power transmission line transmission.10kV transmission lines for power grid construction and transformation are preferred.
3.Steel core aluminum stranded wire core overhead insulated cables with rated voltage of 10kV and below are suitable for overhead power distribution lines with AC rated voltage of 10kV and below.}

 ^{Product Advantages
1.High reliability of power supply
Overhead cables can greatly reduce all kinds of short-circuit faults.Compared with overhead bare conductors, the failure rate is 4-6 times lower.
2.Good power supply security
Overhead cables greatly reduce the risk of personal injury from electric shock
3.Convenient erection and maintenance
The overhead cable can be erected on any kind of pole tower or along the wall.In special cases, it can also be traversed through the trees and directly fixed on the pole with metal fittings.
Overhead cables do not need to be subject to special patrol inspections, nor will short-circuit trip accidents be formed due to flashover of branches, littering by residents, or accidental collision of crane booms, which greatly reduces the maintenance and repair work of the line.
4.Reasonable economy
Lower overall cost, more economical and more reasonable}
