Double Sc Shield Coaxial Cable Rg393 for Equipment
Jiangsu Elesun Cable Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, LAN Cable, RF Cable
- Conductor Material：Copper
- Cover Material：FEP
- Type：50ohm Coaxial Cable
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：rg393
- Wire Core Material：Sc,Sccs
- Certification：CE, ISO, RoHS, CCC, UL
- Model：Rg393
- Brand：Elesun
- Color：Customized
- Print Text：Customized
- Leadtime：10 Days<1000m
- Sample：Free
- Transport Package：Wooden Reel,Box
- Specification：500m,reel 200m,reel
- Trademark：Elesun
- Origin：Zhenjiang
- HS Code：8544200000
- Production Capacity：10000km,Month
Description
RG393 coaxial cable specifications
Material of Inner Conductor
Silver Copper
Structure of Inner Conductor
1/2.38mm
Material of Insulation
PTFE
Diameter of Insulation
7.24mm
Material of Braiding(Shielding)
Silver Copper
Structure of Braiding(Shielding)
144+168*0.15mm
Material of Jacket
FEP
Diameter of Jacket
9.91mm
Working temp
-55ºC/200ºC
Impedance
50Ω±2
Voltage
7500V
Q: What 's the MOQ of cable ?
MOQ ususally 1km and lead time 10 days. It will be 15 days if customize cable assembly .
Q : Can i get a sample ?
Yes, we offer
Q: Could you print text on cable ?
It is no problem to print customer text .
Q: May i know the package style ?
Package will do according customer needs .
