UL 2651 2.0mm/1.27mm/2.54mm Flat Cable Ribbon 26 AWG Cable
CB (XIAMEN) INDUSTRIAL CO., LTD.- Type：Insulated
- Conductor Type：Stranded
- Application：Many Places
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：UL 2651
- Material Shape：Round Wire
- Range of Application：Many Places
- Certification：ISO9001, UL, RoHS, VDE
- Brand：Bort
- OEM：Yes
- Color：Customized
- Delivery Time：3-10days
- Sample：Avaliable
- Transport Package：Carton
- Specification：Customized
- Trademark：Bort
- Origin：Fujian China
- HS Code：8544492900
- Production Capacity：999999meters,Month
Description
Flat Cable. Rating 105 deg C, 300 Vac, Horizontal flame. Conductor 36 AWG - 14 AWG, solid or stranded. Insulation Extruded PVC or heat laminated PVC, 9 mils minimum average thickness, 7 mils minimum thickness at any point. Assembly Two - 150 conductors. Top or bottom layers may form ridges. Sections of the cable may be split into singles or groups of conductors. Shield Optional. Covering Optional. Extruded PVC, 5 mils minimum thickness at any point, 80 mils maximum thickness. Standard Appliance Wiring Material UL 758. Marking General. Use Internal wiring of Electronic equipment.
