Wholesale Underwater Rg58 50 Ohm Coaxial Cable 3c-2V for Communication
Jiangsu Elesun Cable Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, Long Distance Symmetric Cable, RF Cable, Submarine Cable, Antenna Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Rg58
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：RG58
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, CCC, UL
- Model：Rg58
- Brand：Elesun
- Material of Inner Conductor：Bare Copper
- Structure of Inner Conductor：1,0.90mm
- Material of Insulation：Solid PE
- Diameter of Insulation：2.95mm
- Material of Braiding(Shielding)：CCA, Bare Copper, Tinned Copper
- Structure of Braiding(Shielding)：96*0.12mm
- Material of Jacket：PVC
- Diameter of Jacket：5.0mm
- Working Temp：-40ºC,80ºC
- Impedance：50Ω±2
- Voltage：1900V
- Weight：40kg,Km
- Transport Package：500m,Roll,CTN
- Specification：32.5*31*16.5cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544200000
- Production Capacity：10000m,Day
Description
RG58/U coaxial cable specificationsMaterial of Inner Conductor Bare Copper Structure of Inner Conductor 1/0.90mm Material of Insulation Solid PE Diameter of Insulation 2.95mm Material of Braiding(Shielding) CCA, Bare Copper, Tinned Copper Structure of Braiding(Shielding) 96*0.12mm Material of Jacket PVC Diameter of Jacket 5.0mm Working temp -40ºC/80ºC Impedance 50Ω±2 Voltage 1900V Weight 40KG/KM
