Rg214 Rg223 PE LSZH PVC Jacket Telecommunication Coaxial Cable
Jiangsu Elesun Cable Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, LAN Cable, RF Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC,PE,TPU,LSZH
- Type：50ohm Coaxial Cable
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：RG223 RG214
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, CCC, UL
- Model：Rg223 ,Rg214
- Brand：Elesun
- Color：Customized
- Print Text：Customized
- Leadtime：7 Days<3000m
- Transport Package：Wooden Reel,Box
- Specification：1000m,reel 500m,reel
- Trademark：Elesun
- Origin：Zhenjiang
- HS Code：8544200000
- Production Capacity：10000km,Month
Description
RG214/U coaxial cable specifications
Material of Inner Conductor
SC(Silver Copper)
Structure of Inner Conductor
7/0.75mm
Material of Insulation
Solid PE
Diameter of Insulation
7.24mm
Material of Braiding(Double Shielding)
SC(Silver Copper)
Structure of Braiding(Double Shielding)
144+168*0.15mm
Material of Jacket
PVC
Diameter of Jacket
10.80mm
Working temp
-40ºC/80ºC
Impedance
50Ω±2
Voltage
5000V
Weight
160KG/KM
RG223/U coaxial cable specifications Material of Inner Conductor SC(Silver Copper) Structure of Inner Conductor 1/0.90mm Material of Insulation Solid PE Diameter of Insulation 2.95mm Material of Braiding(Double Shielding) SC(Silver Copper) Structure of Braiding(Double Shielding) 112+128 *0.12mm Material of Jacket PVC Diameter of Jacket 5.30mm Working temp -40ºC/90ºC Impedance 50Ω±2 Voltage 1900V Weight 55KG/KM
