UL1061 30-14AWG Srpvc Insulated Electric Wire

Jiangyin Yuanda Electrical Material Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Overhead, Heating, Underground
  • Conductor Material：Bare Copper or Tinned Copper
  • Insulation Material：Srpvc
  • Material Shape：Round Wire

Base Info

  • Model NO.：UL1061
  • Range of Application：Inner Wire of Electric and Electronic Equipment
  • Certification：ISO9001, UL, CCC, RoHS, VDE
  • Brand：Yuanda
  • Color：on Request
  • Temperature Range：80deg.C
  • Nominal Voltage：300V
  • Reference Standard：UL758, UL1581
  • Certificate No.：E216252
  • Test：UL VW-1, Culft1 and Jqaf-Mark Flame
  • Transport Package：Pallet,Carton,Tray,Reel
  • Specification：10-30AWG
  • Trademark：Yuanda
  • Origin：Wuxi, China
  • HS Code：8544492100
  • Production Capacity：1000km,Day

Description

Part No.ConductorInsulationMax Resistence at 20ºC
Ω/kmAWGNO./mmDiameter
mmNom. Thickness
mm±0.1Outer Diameter
mmUL1061307/0.1020.300.250.80354.33UL1061287/0.1270.380.250.88223.75UL1061267/0.1600.480.250.98139.76UL10612411/0.1600.610.251.1188.36UL10612217/0.1600.760.251.2660.16UL10612021/0.1780.940.251.4438.58UL10611834/0.1781.200.251.7022.98UL10611626/0.2541.500.252.0015.06UL10611441/0.2541.880.252.389.59


UL1061 30-14AWG Srpvc Insulated Electric Wire
