UL3122 Heat Resistant Silicone Rubber Copper Wire Cable
CB (XIAMEN) INDUSTRIAL CO., LTD.- Type：Insulated
- Conductor Type：Stranded
- Application：Interal Wiring of Appliance
- Conductor Material：Copper
- Sheath Material：No
- Insulation Material：Silicone Rubber
Base Info
- Model NO.：UL3122
- Material Shape：Round Wire
- Range of Application：Internal Wiring of Appliance
- Certification：ISO9001, UL, RoHS, Reach
- Brand：Bort
- Braiding：Fiberglass
- Transport Package：Roll, Customization
- Specification：AWG16-26
- Trademark：Bort
- Origin：China
- HS Code：8544492900
- Production Capacity：500000km,Per Year
Description
ConductorInsulation Fiberglass Thickness Max Resistance 20ºC AWG CONSTRUCTION Diameter Thickness Diameter NO./mm mm mm mm mm Ω/KM 26 7/0.16 0.48 0.40 1.60 0.15 150.00 24 7/0.20 0.61 0.40 1.70 0.15 94.20 22 7/0.254 0.78 0.46 2.00 0.15 59.40 20 7/0.30 0.93 0.46 2.15 0.15 36.70 20 20/0.18 0.93 0.46 2.15 0.15 36.70 18 7/0.39 1.20 0.40 2.30 0.15 23.20 18 30/0.18 1.15 0.40 2.25 0.15 23.20 16 7/0.49 1.50 0.40 2.60 0.15 14.60 16 50/0.18 1.50 0.40 2.60 0.15 14.60
