Outdoor Double Armored G652 Fiber Optic Cable

DONGGUAN TW-SCIE CO., LTD.
  • Application:Communication, G652 Fiber Optic Cable
  • Type:Single-mode Fiber
  • Connection Structure:G652 Fiber Optic Cable
  • Material Shape:Round Wire
  • Allowed Lateral Pressure:Short Term 3000n; Long Term 1000n
  • Allowed Tensile Strength:Short Term 3000n; Long Term 1000n

Base Info

  • Model NO.:GYTA53 G652 Fiber Optic Cable
  • Core:2-288 Core
  • Certification:RoHS, ISO9001, Reach,Tlc,etc
  • Brand:Tw-Scie or OEM
  • Sheath Material:MDPE , HDPE , Lszh PE
  • Model No:GYTA53 G652 Fiber Optic Cable
  • Fiber Count:2-288 Core
  • Brand Name of Fiber:Corning ,Yofc,Draka, ...as Your Requiremen
  • Loose Tube Material:PBT
  • Loose Tube Filling Material:Jerry
  • Color of Loose Tube:Blue,Orange,Green, Brown,Grey, White,Red etc
  • Central Strength Member:Steel Wire or FRP
  • Double Armour Material:Corrugated Steel and Aluminium Tape
  • Core Moisture Protection Methodology:Water Blocking Tape or Filling Compound
  • Installation Style:Direct-Burial and Duct
  • Transport Package:Wooden Drum
  • Specification:SGS ROHS REACH ISO
  • Trademark:TW-SCIE or OEM
  • Origin:Dongguan, Guangdong, China (Mainland)
  • HS Code:854470000
  • Production Capacity:200km,Day

Description


Technical data:Fiber Num.Outer diameter (mm)Weight (kg/km)Min.Bending radius(mm)Tension (N)Crash loading (N/100mm)StaticDynamicShort termLong termShort termLong term2-2413.321012.5 times O.D.25 times O.D.300010003000100026-3613.622038-6014.122562-7214.625574-9616.230598-12017.7350122-14419.1395146-21619.6420218-24022.8530242-28825620
GYTA53 Outdoor Double Armored G652 Fiber Optic Cable Packaging Detail:
GYTA53 Outdoor Double Armored G652 Fiber Optic Cable package are  wooden drum.
Outdoor cable's delivery length according to 2-288 Core Optical Fiber Cable cores. Also accept custom cabledrum from customers. welcome to contact us!

Our Quality & Service:
DONGGUAN TW-SCIE CO., LTD. is committed to providing the highest quality optical fiber cable products & services to our customers by:
1.Consistently meeting for product quality and performance;
2. Timely delivery of products and services to meet our customer's requirements;
3. Ensuring that our people are properly trained so that they are better able to serve our customers.

Our Certificate:
REACH
ROHS
TLC Telecom Certificate
Environmental Management System Certification
ISO9001:2000
Utility Model Patent Certificate

As professioanl manufacturer on optical fibre cables, we can not only offer you optical fibre cables with high quality and competitive price, but also the structures as your requirment. So please feel free to contact with us for cooperation and excellent service.

Contact with me for this GYTA53 Outdoor Double Armored G652 Fiber Optic Cable.
