UL1061 Insulation Hook up Wire Stranded Solid Copper Conductor
CB (XIAMEN) INDUSTRIAL CO., LTD.- Type:Insulated
- Conductor Type:Stranded
- Conductor Material:Copper
- Sheath Material:PVC
- Insulation Material:PVC
- Material Shape:Round Wire
Base Info
- Model NO.:UL1061
- Certification:ISO9001, UL, RoHS
- Brand:Bort
- Sample:Free Sample Available
- Packaging:610m,Roll
- Color Available:Any Colors
- Delivery Time for Samples:3-5days
- Delivery Time for Mass Production:7-30days
- Appliance:Internal Wiring of Electronic&Electrical Equipment
- Warranty Time:at Least 10 Years for Proper Use
- Factory Management Standard:ISO9001:2008
- Annual Capacity:300,000km
- Transport Package:Roll or Spool Packing, Stretch Film Wrapping, Car
- Specification:customize
- Trademark:Bort
- Origin:Zhangzhou
- HS Code:8544492900
- Production Capacity:300000km,Year
Description
Maximum Resistance at 20ºC
Ω/kmAWG No./mm Dia.
mm Nom. Thick.
mm Nom.Dia.
mm 30 7/0.1 0.3 0.26 0.82 354 28 7/0.127 0.38 0.26 0.9 223 26 7/0.16 0.48 0.26 1 139 24 11/0.16 0.61 0.27 1.15 88.9 22 17/0.16 0.76 0.26 1.28 57.5 20 26/0.16 0.94 0.26 1.46 34.6 18 41/0.16 1.18 0.26 1.7 23.3 16 26/0.254 1.49 0.26 2.02 15.1
Ω/km
mm
mm
mm
