Pre-Made Coaxial Cable 5D-FB Cable Assembly with SMA Plug for Antennas
Otto Cable Technology Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, RF Cable
- Conductor Material：BC,CCA
- Cover Material：PVC,PE,LSZH
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：5D-FB
- Wire Core Material：BC,CCA
- Certification：CE, ISO, RoHS
- Model：5D-FB
- Brand：Otto Cable
- Transport Package：Pallet; Carton; Spool
- Specification：7.5mm
- Trademark：OTTO CABLE
- Origin：Zhejiang, China
- HS Code：854420
- Production Capacity：150km,Day
Description
Basic Info.
Model NO. 5D-FB Wire Core Material BC/CCA Certification CE, ISO, RoHS Model 5D-FB Brand Otto Cable Transport Package Pallet; Carton; Spool Specification 7.5mm Trademark OTTO CABLE Origin Zhejiang, China HS Code 854420 Production Capacity 150km/DayProduct Description
Pre-Made Coaxial Cable 5D-FB Cable Assembly with SMA Plug for Antennas
Application:
• Antennas
• Base Station Atenna
• Cellphone Signal Repeaters
• Signal transmission
Features:
• 50 Ohm
• Good shielding effectiveness
• 0 - 6GHz
• Excellent performance at high frequency
• Equivalent to LMR300 cable
• REACH/RoHS compliant, CE certified.
• OEM/ODM
Assemblies:
• N, TNC, BNC, SMA......
• Customized Cable length / color/ roll size/ packing
• Various colors of Heat shrinkable tube
Construction
| Item | Material | Diameter(mm) |
| Inner Conductor Dielectric First Shield Second Shield Jacket | Bare Copper / Copper Clad Aluminum Foam PE Bonded Aluminum Foil Tinned Copper / Al-Mg Wire Braid PVC/PE/LSZH | 1.80 5.00 5.10 5.60 7.50 |
Electrical Characteristics
| Impedance (Ω) Capacitance (pF/m) Velocity of Propagation (%) Return Loss Screening Effectiveness(db) VSWR Installation Temp(ºC) Operating Temp(ºC) Bending radius(mm) | 50±3 82 82.0 ≥20 ≥75 ≤1.2 -25 to +70 -25 to +70 27.0 |
Attenuation (@20ºC)
| Frequency(MHz) | Max Attenuation(dB/100m) |
| 800 1200 1500 1800 2000 2500 3000 | 19.0 24.0 27.2 29.7 32.5 35.8 40.9 |
