• Model NO.：GYXTW
• Core：Multicore
• Certification：CE, ISO9001
• Brand：OEM
• Sheath Material：PE
• Name：GYXTW Outdoor Fiber Optical Cable
• Number of Cores：2--48
• Temeprature：-40--60
• Outer Sheath：PE
• Color：Black
• Fiber Type：Sm mm Om2
• Transport Package：Wooden Drum or Iron-Wooden Drum
• Specification：ISO9001
• Trademark：JingLong
• Origin：China(Mainland)
• HS Code：8544700000
• Production Capacity：3000km,Month

Basic Info.

Model NO. GYXTW Core Multicore Certification CE, ISO9001 Brand OEM Sheath Material PE Name GYXTW Outdoor Fiber Optical Cable Number of Cores 2--48 Temeprature -40--60 Outer Sheath PE Color Black Fiber Type Sm mm Om2 Transport Package Wooden Drum or Iron-Wooden Drum Specification ISO9001 Trademark JingLong Origin China(Mainland) HS Code 8544700000 Production Capacity 3000km/Month

Product Description

GYXTW 4 6 8 12 24 48 Core Fiber Optical Cable Price Per Meter For SaleMetallic strength member ,central tube ,gel filling ,two parallel steel wires embedded in the out sheath ,corrugated steel plastic tape  and polyethylene sheath outdoor cable for communication purpose .

GYXTW outdoor fiber optical cable
Type: Center tube type with two steel wires
The way: Aerial and duct
Waterblocking: Jelly


The unique fiber excess length control method provides the cable with excellent tension and environmental properties
The loose tube material itself have good water-resistant properties of solution and higher intensity, Special jelly filled in the loose tube provides the fibers with critical protection
Excellent crush resistance performance and flexible performance
The out PE sheath provides good anti-UV radiation performance
Adopt the following measures to ensure the waterproof properties of optical fiber cable
The unique waterproof compounds filled in the loose tube
Safety-filled cable core

1.Selected high quality optical fiber ensure the optical fiber cable have excellent transmission properties.
2.The unique fiber excess length control method provides the cable with excellent mechanical and environmental properties.
3.Very strict material and manufacturing control guarantees the cable can work stably for more than 30 years.
4.Total cross-section water-resistant structure makes cable have excellent properties of moisture resistance.
5.Special jelly filled in the loose tube provides the fibers with critical protection.
6.The out PE sheath provides good anti-UV radiation performance.
