Manufacture 450/750V Copper Conductor XLPE Insulationelectric Wire for Building
Jiangsu Elesun Cable Co., Ltd.- Conductor Type：Stranded
- Application：Overhead, Heating, Underground, Electric Wire
Base Info
- Model NO.：electric wire
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
- Material Shape：Round Wire
- Range of Application：Electric
- Certification：ISO9001, CE, UL, CCC, RoHS
- Brand：Elesun
- Conductor：Strand Bare Copper Wire
- Insulation：PVC
- Color：Black,White,Red,Yellow,Blue,and etc.,
- Black,White,Red,Yellow,Blue,and etc.,：PVC or Lsoh
- Number of Cores：2-24 Cores
- Cross Section：0.75-2.5mm2,0.5,2.5,3.5mm2
- Voltage Rating：300,500V
- Temperature Rating：-30~ +70ºC
- Testing Voltage：2000V,5min
- Reference Standard：IEC60227
- Transport Package：305m,Roll
- Specification：32.5*31*16.5cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544492100
- Production Capacity：10000m,Day
- Package size per unit product：29.00cm * 29.00cm * 26.00cm
- Gross weight per unit product：15.000kg
Description
RV(60227IEC06) 300/500V Single Core PVC Insulation FlexibleElectric Wire
Nominal Cross( mm²)
Conductor Structure(mm)
Insulation Thickness (mm)
O.D. Of Cable(mm)
Max Resistance @20ºC(Ω/KM)
Min. Resistance @70ºC(Ω/KM)
0.5
1/0.80
0.6
2.0
36.0
0.015
0.75
1/0.97
0.6
2.17
24.5
0.012
1.0
1/1.13
0.6
2.33
18.1
0.011
