50 Ohm RF Corrugated Coax Cable (1/2")

Otto Cable Technology Co., Ltd.
  • Application：Local Communication Cable, Coaxial Cable, RF Cable
  • Conductor Material：Copper
  • Cover Material：PE
  • Type：Coaxial
  • Material Shape：Round Wire
  • Conductor Type：Solid

Base Info

  • Model NO.：1,2"
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS
  • Inner Conductor：CCA
  • Insulation：Foam PE
  • Shield：Bc
  • Jacket：PVC,PE,Lszh
  • Transport Package：200m,Roll, 500m,Drum
  • Specification：CE, RoHS
  • Trademark：OTTOCABLE
  • Origin：China
  • HS Code：8544200000
  • Production Capacity：50km,Day

Description


RF Feeder Cable 1/2"ConstructionItemMaterialDiameter(mm)Inner ConductorCopper Clad Aluminum4.8Dielectric Foam PE12.0ShieldCorrguated Copper Tube/ Aluminum Tube13.9JacketPVC/PE/LSZH15.7 Electrical CharacteristicsAttenuation @20ºC (dB/100M)Impedance(Ω)50@150MHz2.7Velocity of Propagation(%)88@200MHz3.1Return Loss(dB)≥20@300MHz3.83Capacitance76@450MHz4.75Shielding Effectiveness(dB)≥90@800MHz6.46Operating Temperature(ºC)-30 to +70@1000MHz7.2850 Ohm RF Corrugated Coax Cable (1/2")
50 Ohm RF Corrugated Coax Cable (1/2")
