RG58 Coax Jumper Cable/ Pigtail Designed for Antennas
Otto Cable Technology Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, RF Cable
- Conductor Material：Tc,Bc,CCS
- Cover Material：PVC
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：RG58
- Wire Core Material：Tc,Bc,CCS
- Certification：CE, ISO, RoHS
- Model：Rg58
- Brand：Otto
- Inner Conductor：Tc,Bc,CCS
- Insulation：Solid PE
- Shield：Tc,Bc,CCA
- Jacket：PVC
- Transport Package：Carton
- Specification：CE, RoHS, SGS
- Trademark：OTTO
- Origin：China
- HS Code：8544211000
- Production Capacity：1000PCS,Day
Description
RG58 Coaxial CableConstruction Item Material Diameter(mm) Inner Conductor TC / BC / CCS 1*0.9 / 19*0.18 Dielectric Solid PE 2.95 Shield TC / BC/ CCA Braid(80,96,112,128) 3.45 Jacket PVC 4.95 Electrical Characteristics Attenuation @20ºC (dB/100M) Impedance(Ω) 50 @100MHz 15.2 Velocity of Propagation(%) 66 @500MHz 42.6 Shielding Effectiveness(dB) ≥85 @900MHz 53.0 VSWR(dB) 1.25 @1000MHz 56.0 Operating Temperature(ºC) -30 to +70 @2000MHz 79.0 ----- ----- @2500MHz 95.5
