Yjv32 600/1000V 4X300mm2 Underground XLPE Copper Cable Armoured Power Cable

Tianjin Feiya Electric Wire & Cable Co., Ltd.
  • Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Car, to Be Fixedly Laid Indoors, in Tunnel
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：XLPE,PVC
  • Sheath Material：PE,PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：Yjv32
  • Wire Core Material：Copper or Aluminum
  • Certification：ISO, CCC, CE, RoHS, UL, VDE
  • Model：Yjv32
  • Brand：Feiya
  • Temperature Range：-5 Degree Till +70 Degree
  • OEM&ODM：Yes
  • Rated Voltage：0.6,1kv
  • Operating Environment：Underground
  • Material：PVC,PE Jacket
  • Other Service：Can Be Customized
  • Use Place：Power Transmission and Distribution
  • Lowsmokezerohalogan：LSZH, Lsoh, Ls0h, Lsfh, Ohls
  • Colors：Can Be Customized
  • Transport Package：Wooden Box Packing or Pallet Shipping Containers
  • Specification：copper,aluminum,pvc
  • Trademark：Feiya
  • Origin：China
  • HS Code：8544
  • Production Capacity：80000 Meter,Meters Per Month

Description

Part NumberCross SectionStrandingApprox WeightApprox Overall DiameterGland SizeSingle CleatNom. Max. DC-resist conductor 20° CCurrent rating laid direct(mm²)(mm)KG/KM(mm)(mm) (Ohm/km)(Amp)SWAPVC4X1.54 x 1.57/0.5335112.8820s0.512.132SWAPVC4X2.54 x 2.57/0.6742914.4320s0.67.4142SWAPVC4X4.04 x 4.07/0.8553816.87200.64.6155SWAPVC4X6.04 x 6.07/1.0467017.87200.73.0869SWAPVC4X104 x 107/1.3599820.1250.81.8392SWAPVC4X164 x 167/1.701,27222.4250.91.15119SWAPVC4X254 x 257/2.141,940273210.727152SWAPVC4X354 x 357/2.522,39030.1321.20.524182SWAPVC4X504 x 5019/1.782,92531.5321.40.387217SWAPVC4X704 x 7019/2.144,20037.4401.60.268266SWAPVC4X954 x 9519/2.525,35540.950s1.80.193319SWAPVC4X1204 x 12037/2.036,92546.65020.153363SWAPVC4X1504 x 15037/2.258,20050.250s20.124406SWAPVC4X1854 x 18537/2.529,97555.863sTC90.0991458SWAPVC4X2404 x 24061/2.5212,70062.563TC100.0754529SWAPVC4X3004 x 30061/2.8515,27567.475sTC110.0601592SWAPVC4X4004 x 40061/3.2019,8757775TC120.047667



Look for customised cables? Get more information connect with Daisy







Yjv32 600/1000V 4X300mm2 Underground XLPE Copper Cable Armoured Power Cable



Yjv32 600/1000V 4X300mm2 Underground XLPE Copper Cable Armoured Power Cable



Yjv32 600/1000V 4X300mm2 Underground XLPE Copper Cable Armoured Power Cable
Q1: Are you a trading company or manufacturer?

A1: Tianjin Feiya wire & Cable Co., Ltd. is a professional manufacturer.

Q2: What kinds of products does Tianjin Feiya wire & Cable Co., Ltd. Manufacture?

A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable, PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable, coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.

Q3: Which standards do you comply with when you produce the electrical wires and cables?

A3: We have passed ISO9001: 2000 and ISO140001: 2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).

Q4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.

Q5: How much the Courier freight will be for the samples?

A5: Courier freight depends on the quantity, weight and carton size and your area.
