3, 4, 5 Copper Core Electric Power Cable Yjv22 0.6/1kv

People's Cable Group Co., Ltd.
  • Application：Construction, Underground, Industrial, Power Station, Car
  • Voltage：Low and Medium Voltage Cable
  • Current：DC & AC
  • Insulation Material：XLPE
  • Sheath Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：yjv22
  • Wire Core Material：Bare Copper Wire
  • Certification：ISO, CCC, CE
  • Model：Yjv22
  • Brand：Rmjt
  • Standard：IEC 60502
  • Material：Copper,Aluminum
  • Sheath Matieral：PVC,XLPE
  • Core：1~5
  • Insulation：PVC,XLPE
  • Delievry Time：7~20 Days
  • MOQ：1000 Meters
  • Payment：20%~30% Advanced
  • Transport Package：Strong Wooden Drum
  • Specification：10MM2~500MM2
  • Trademark：RMJT
  • Origin：China
  • HS Code：8544492100
  • Production Capacity：3000meter,Day

Description

Model                       NameYJV
YJLVCU or AL conductor ,XLPE/pvc  insulated PVC sheathed electric cableYJV22
YJLV32Cu or Al conductor XLPE /pvc insulated steel tape armoured ,steel wire armor
pvc sheathed electric cable

XLPE insulated power cable 0.6/1kvnorminalsectional area insulati-on thicknessheath thickness(mm)overal diameter
of cable (mm)D.C resistance of conductor(km)                current ratingin air(A)direct in soil(A)cuAlcuAlcuAl1×1.50.71.56<=12.1<=12.1302545351×40.71.57<=7.41<=7.41453560501×60.71.57<=3.08<=4.61554570551×350.91.512<=0.524<=0.8681751401901501×5011.513<=0.387<=0.6412101702251801×701.11.514<=0.268<=0.4432702152802251×951.11.516<=0.193<=0.3203402753352701×1201.21.518<=0.153<=0.2534003203803051×1501.4221<=0.124<=0.2064603704253401×1851.6223<=0.0991<=0.1645304154803751×2401.7225<=0.0754<=0.125625490555435…         3×1.50.71.510<=12.1<=12.1252530303×2.50.71.511<=7.41<=12.1302535303×40.71.512<=4.61<=7.4140305040…        Attention: We can provide more info than above data, if needed.The above are just some examples.
TYPEDescription of Cable
 Main Applications
 CU coreAL coreVVVLVCopper/Aluminium core,PVC insulated,PVC sheathed power cableNon-armoured PVC cable are suited for laying indoors,In cable trench,On cable racks and in pipes. Unable bear external pressures and tensions.VYVLYCopper/Aluminium core,PVC insulated,PE sheathed power cableVV22VLV22Copper/Aluminium core,PVC insulated,steel tape armored,PVC sheathed power cableSteel-tape armoured PVC cables are suited for vertical burial.Can bear moderate positive pressures,Unable bear tension forces.VV23VLV23Copper/Aluminium core,PVC insulated,steel tape armored,PE sheathed power cableVV32VLV32Copper/Aluminium core,PVC insulated,thin steel wire armored,PVC sheathed power cableThin steel wire armoured PVC cables are used in case of great difference of levels or vertical installation and Can do vertical burial.Can bear moderate positive pressures and tension forces.VV33VLV33Copper/Aluminium core,PVC insulated,thin steel wire armored,PE sheathed power cableVV42VLV42Copper/Aluminium core,PVC insulated,thick steel wire armored,PVC sheathed power cableThick steel wire armoured PVC cables are suited for vertical installation and can be laid water or sea-bottom.Can bear greater positive pressures and tension forces.VV43VLV43Copper/Aluminium core,PVC insulated,thick steel wire armored,PE sheathed power cable
TypeDescriptionApplicationCu CoreAl CoreYJV
ZR-YJVYJLV
ZR-YJLVCu(Al)Core, XLPE Insulated, PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, PVC Sheathed flame- retardant Power CableCan be laid in indoor, outdoor, tunnels, cable channels, reinforced concrete pipelines and loose soil. Cable should not bear outer mechanic force, but can bear a certain tractional force.YJV22
ZR-YJV22YJLV22
ZR-YJLV22Cu(Al)Core, XLPE Insulated, Steel Tape Armored and PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, Steel Tape Armored and PVC Sheathed flame- retardant Power CableLaid underground. Cable can bear outer mechanic force, but should not bear large tractional force.YJV32
ZR-YJV32YJLV32
ZR-YJLV32Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed flame- retardant Power CableLaid in indoor, tunnels and mines. Cable can bear outer mechanic force and fairly large tractional force.YJV42
ZR-YJV42YJLV42
ZR-YJLV42Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed Power Cable
Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed flame- retardant Power CableCan be laid in vertical section, indoor, tunnels and mines. Cable can bear outer mechanic force and very large tractional force.
Product Line:
As one of top rank cables manufacturers in China, our Zhitian factory is mainly specialized in PVC Insulated Building Wire, PVC and XLPE Insulated Power Cable with Voltage up to 35kV, Rubber Cable and Welding Cables. And the Zhulin factory is mainly specialized in Aerial Bundled Cable(ABC Cable), Bare Overhead Power Transmission Line such as All Aluminum Conductor(AAC Conductor), All Aluminum Alloy Conductor(AAAC Conductor), Aluminum Conductor Steel Reinforced(ACSR Conductor), Aluminum Conductor Aluminum Clad Steel Reinforced (ACSR/AW), All Aluminum Alloy Steel Reinforced(AACSR), and Aluminum Conductor Aluminum Alloy Reinforced(ACAR).3, 4, 5 Copper Core Electric Power Cable Yjv22 0.6/1kv

Our Customers:

We have a professional sales team with each of them has engaged in this job for 3-10 years, so that we can provide the comprehensive and professional technology for you. With the perfect quality and after sales service, till now we have exported to more than 80 countries, welcome to visit us and establish win-win establish relationship!3, 4, 5 Copper Core Electric Power Cable Yjv22 0.6/1kv

Our Certificates:

As first rank of the cable supplier in China, we have obtained CCC, ISO9001, ISO14001, OHSAS certificates, passed the SGS and BV test, and our brand "RMJT" has be given China famous brand.
3, 4, 5 Copper Core Electric Power Cable Yjv22 0.6/1kv


FAQ:

1. What is our company's main advantage?

We have produced cables for many years and have rich experience in exporting, and our quality can meet different standards including ASTM, BS, EN, IEC, DIN etc.



2.  What is our payment term?

Generally our payment term is T/T or L/C at sight in trial business.



3. What is the package of the cable ?

The package is strong wooden drum, steel wooden drum or coil, and we can also provide special packing according to customer's requirment.



4. What is the delivery time?

Normally we could send the shipment within 20 days after confirmation. It relates to the cable type, quantity, if you need the specific delivery time or you are urgent, kindly advise us your special needs when you contact us for better checking.



5.Can we provide customers free sample for checking?

Yes, free sample is available for checking, normally courier charge is on customers.
