FTTH Fiber Optic 1310/1490/1550 Fwdm

Shenzhen KOC Communication Co., Ltd.
  • Application：Communication
  • Type：Single-mode Fiber
  • Connection Structure：SC
  • Material Shape：Round Wire
  • Allowed Lateral Pressure：>1000(N,100mm)
  • Allowed Tensile Strength：1000N<10000N

Base Info

  • Model NO.：Fwdm
  • Core：Single Core
  • Certification：RoHS, ISO9001
  • Brand：Koc
  • Sheath Material：PVC LSZH
  • Connector Type：LC,Sc,FC,St or Customize
  • Fiber Tube Diameter：0.9mm,2.0mm
  • Length：0.5m, 1m, 2m,3m Other Length
  • Fiber Type：G657A, G652D
  • Packaging Size：ABS Box, Steel Tube; Lgx
  • Adapter Type：LC,Sc,FC,St
  • Package：Carton, Transparent Box or Cust
  • Transport Package：Carton
  • Specification：SGS; RoHs
  • Trademark：KOC
  • Origin：Guangdongshenzhen
  • HS Code：85176222
  • Production Capacity：10000

Description


ITEMFWDM-5/34FWDM-4/35FWDM-34/5UnitPass Channel wavelength Range1550±101490±101310±40nm1490±10nmReflect Channel wavelength-11310±401310±401550±10nmReflect Channel wavelength-21490±101550±10nmInsertion LossPass Channel<0.60dBReflect Channel<0.60dBInsertion Loss RipplePass Channel≤0.30dBReflect Channel≤0.30dBIsolationPass Channel≥40dBReflect Channel≥20dBReturn Loss>50dBInsertion Loss Temperature Sensitivity<0.005dB/ºCPolarization Dispersion Loss<0.10dBPolarization Mode Dispersion<0.10PsDirectivity≥50dBMax Power Handling500mWOperating Temperature-20~+70°CStorage Temperature-40~+85°CFiber TypeSMF-28e,Bare OR 0.9mm Loose TubePackage Dimension¢5.5XL32 OR ABS BOXmm


Note1: All values specified are without connectors.
