UL20276 Tinned Copper PVC Insulated Electrical Wire HDMI Cable
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：for General Purpose Internal Wiring of Appliance
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：Teflon
Base Info
- Model NO.：UL20276
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE, Reach
- Brand：B&T
- According to：UL Subject758, UL1581
- Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
- Conductor：Stranded, Tinned or Bare Copper Conductor
- Company Type：Manufacturer
- Factory Directly：Big Discount with Large Order
- Service：OEM, ODM
- Sample：Conventional Sample Free
- Producing Experience：10 Years
- No. of Cores：One Core or Multi-Cores
- Colors：Could Be Customized Color
- Transport Package：610 Feet in Roll
- Specification：18~30AWG 1~34 Conductors
- Trademark：B&T
- Origin：Xiamen, Fujian
- HS Code：8544492100
- Production Capacity：300, 000km
Description
Maximum Resistance at 20 ºC
Ω/kmAWG No./mm Nom./Dia.
mm Nom. Thick.
mm Nom.Dia.
mm Material Coverage Nom. Thick.
mm Dia.
mm 3P 26 7/0.16 0.48 0.26 1.00 - PAPER 82% 1.05 6.40 139 1C 26 7/0.16 0.48 0.26 1.00 139 3P 28 7/0.127 0.38 0.12 0.63 7/0.16 AL 95% 0.56 4.70 223 9C 28 7/0.127 0.38 0.12 0.63 223 6P 28 7/0.127 0.38 0.12 0.63 7/0.127 PET 70% 0.70 4.70 223 7P 28 7/0.127 0.38 0.12 0.63 - PAPER 90% 0.95 5.30 223 8P 28 7/0.127 0.38 0.12 0.63 7/0.127 PET 74% 0.70 5.00 223 12P 28 7/0.127 0.38 0.12 0.63 7/0.2 AL 84% 1.00 6.70 223 1C 28 7/0.127 0.38 0.12 0.63 223 13P 28 7/0.127 0.38 0.12 0.63 7/0.2 AL 85% 0.92 7.00 223 18P 28 7/0.127 0.38 0.12 0.63 - AL 80% 0.76 7.40 223 19P 30 7/0.1 0.30 0.15 0.60 7/0.127 AL 85% 1.28 8.50 354 25P 30 7/0.1 0.30 0.15 0.60 7/0.127 AL 85% 1.39 9.50 354 25P 28 7/0.127 0.38 0.12 0.63 - AL 80% 0.72 8.20 223
Our products can meet UL, VDE, CCC, PSE certificate requirement and the products are accord with ROHS and REACH Halogen free standard.
Our factory could meet ISO9001:2008 management systems standard. There are 6 production lines in high quality, precise, automation which supporting daily capacity 300,000km cables at least.
Q1: Can I get a free sample?
A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?
A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?
A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?
A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?
A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6: Where is your main market?
A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.
Our Services
1. Professional QC and QA team to make sure all products qualified before shipping.
2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional service
Why choose us
1. Production
Qualified production, competitive price, professional service.
2. Technology
Professional R& D team
3. Equipment
With completive testing equipment.
4. Quality
UL/ CE/ FCC/ RoHS/ Reach certificate
