Silicone Rubber Insulated Wire with High Temperature
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Heating
- Conductor Material：Copper or Tinned Copper
- Sheath Material：Silicone Rubber
- Insulation Material：Silicone Rubber
Base Info
- Model NO.：UL3139
- Material Shape：Round Wire
- Range of Application：High Temperature
- Certification：ISO9001, UL, CCC, RoHS, VDE, CSA
- Brand：Yuanda
- Spec AWG：26 - 12
- Color：as The Customer Requires
- MOQ：3000 Meters
- Delivery：Within 25 Days
- Certificate No.：E216252 CSA229260
- Packaging：100m,Roll(as The Customer Requires )
- Transport Package：Carton,Pallet,Tray,Reel
- Specification：26-12AWG
- Trademark：Yuanda
- Origin：Wuxi, China
- HS Code：8544492100
- Production Capacity：1000km,Day
Description
ConductorInsulation Electrical characteristic Spec
AWG Conductor
construction
No./φmm Diameter
(mm) Nominal
thickness
(mm) Nominal outer
diameter
(mm) Max outer
diameter
(mm) Resistance
20°c
Ω/km Premissible ampacitity
20°c - AMR 26 1/0.40 0.4 1.18 2.76 3.04 143.0 3.22 24 1/0.50 0.5 1.18 2.86 3.15 92.0 5.15 22 1/0.60 0.6 1.18 2.96 3.26 56.8 8.73 20 1/0.80 0.8 1.18 3.16 3.48 40.1 13.87 18 1/1.0 1 1.18 3.36 3.7 23.0 22.02 16 1/1.20 1.2 1.18 3.56 3.92 14.6 35.04 14 18/0.39 1.9 1.18 4.26 4.69 9.9 55.68 12 28/0.39 2.4 1.18 4.76 5.24 5.38 88.4
Our main products are as follows:
Automotive cable that meet the national standard, Japanese standard, American standard, German standard, France and other countries' standards, etc.. Coaxial cables that are widely used in various fields of communication systems. Cables that suitable for motor, railway, urban rail and rolling stock. Electronic cable and sleeves that widely used in electronics, electrical appliances, household appliances instruments etc.. Cables used in special fields like photovoltaic, nuclear power, aviation and ships. Our products involved in cross-industry, many fields.
Our main customers are as follows:
Shanghai Sanzhi, Delphi, Lear-stec and Continental-corporation that matching Ashkenazi vehicle; THB Group and Ingersoll Rand eytc. ewire harness corporation that matching European and American vehicle; as well as Dell, Lenovo, Huawei and other matching communication cable customers and Panasonic, Siemens, Midea, Gree and other electronic cable customers.
If you are interested in our products, please contact with us! Also, you can tell us your requirements, and we can produce for you.
