• Model NO.：OPGW
• Core：Multicore
• Certification：ISO9001, CCC, BV
• Brand：Rmjt
• Sheath Material：Bare
• Voltage：High Voltage
• Product Name：Outdoor Optical Fiber Composite Aerial Ground Wire
• Usage：Signal Transimision Line
• Key Name：Fiber Optic Cable
• Feature：Fiber Optic
• Transport Package：Wooden Drum
• Specification：ASTM BS GB IEC DIN
• Trademark：RMJT
• Origin：China
• HS Code：8536700000
• Production Capacity：10000000meters,Year

Cable model

OPGW-60

OPGW-70

OPGW-90

OPGW-110

OPGW-130

Number /diameter(mm) of stainless steel tube

1/3.5

2/2.4

2/2.6

2/2.8

1/3.0

Number /diameter of AL wire(mm)

0/3.5

12/2.4

12/2.6

12/2.8

12/3.0

Number /diameter of ACS wire(mm)

6/3.5

5/2.4

5/2.6

5/2.8

6/3.0

Diameter of Cable (mm)

10.5

12.0

13.0

14.0

15.0

RTS(KN)

75

45

53

64

80

Cable weight (kg/km)

415

320

374

432

527

DC resistance(20⁰C W/km)

1.36

0.524

0.448

0.386

0.327

Modulus of elasticity(Gpa)

162.0

96.1

95.9

95.6

97.8

coefficient of Linear thermal expansion(1/ºC×10^-6)

12.6

17.8

17.8

17.8

17.2

Short circuit capacity (kA²s)

24.0

57.3

78.9

105.8

150.4

Max. operation temperature (ºC)

200

200

200

200

200

Max. fiber count

48

32

48

52

30


3.Packing

Packing in wooden drums,steel wooden drums or as customer's requirement.



4.Customer Visit

We have a professional sales team with each of them has engaged in this job for 3-10 years, so that we can provide the comprehensive and professional technology for you. With the perfect quality and after sales service, till now we have exported to more than 80 countries, welcome to visit us and establish win-win establish relationship!




5.Certificate

As first rank of the cable supplier in China, we have obtained CCC, ISO9001, ISO14001, OHSAS certificates, passed the SGS and BV test, and our brand "RMJT" be given China famous brand.


6.About us:

People's Cable Group Co., Ltd. was founded in 2007, located in Zhengzhou Gongyi economic development zone. Our company has 2 factories (Zhitian factory and Zhulin factory), occupies total area of more than 300,000 square meters, with building area 230,000 square meters.



7.Contacts

Chris
