• Model NO.：MPO,MTP Om3 Round Cable Fiber Optic Patchcord
• Core：Multicore
• Certification：RoHS, UL, ISO9001
• Brand：OEM
• Sheath Material：LSZH
• Insertion Loss：0.35
• Return Loss：More Than 50
• Operating Temperature：-20~75 Degree
• Storage Temperature：-40~75 Degree
• Polishing Type：Upc,APC
• Fiber Core：G652D, G657A1, etc.
• Cable Type：Simplex, Duplex, etc.
• Cable Od：0.9mm, 2.0mm, 3.0mm
• Cable Material：PVC, LSZH
• Connector：MPO, Sc, LC, St
• Transport Package：Carton Box
• Specification：patch cord
• Trademark：Opelink
• Origin：China
• HS Code：85367000

ParameterSinglemode PatchcordMultimode PatchcordPolishing  TypePCAPCPCInsertion loss(dB)Max.<=0.7dB<=0.7dB<=0.7dBTypical<=0.35dB<=0.35dB<=0.35dBReturn loss(dB)>=50dB>=60dB≥20dBOperating temperature-20ºC~75ºCStorage Temperature-40ºC~75ºC500 mating cycles lossI.L changed≤0.2dBDurability>1000 cycles

Ordering information:


Type	Fiber Core	Cable Type	Cable OD	Cable Material	Cable Color	Connector (A End -B End)	Patchcord Length
PT=Patchcord PY=Pigtail	S1=G652D S2= G657A1 M1=50/125 M2=62.5/125 M3=OM3 M4=OM4 XX=other	01=simplex 02=Duplex 03=Armoured 04=Distribution 05=Ribbon 06=breakout XX=other	01=OD 0.9mm 02=OD 2.0mm 03=OD 3.0mm XX=other	1=PVC(R) 2=PVC(P) 2=LSZH	01=Blue  02=Orange 03=Green  04=Brown 05=Slate  06=White 07=Red  08=Black 09=Yellow  10=Violet 11=Rose  12=Aqua 13=12Color  XX=other	01=SC  02=FC   03=ST 04=LC  05= E2000 06=SC/APC (Cone Type) 07= SC/APC (Step Type) 08= FC/APC (Cone Type ) 09= FC/APC (Step Type) 10=LC/APC  11=E2000/APC 12=MTRJ    13=MPO/PC 14=MPO/APC   15=D4 16=DIN  17=LX5  18=FDDI 00=None  XX=other	005=0.5m 010=1.0m 020=2m 025=2.5m XXX=other



----------------------------------------------------FAQ---------------------------------------------------

Q1. Can I have a sample order for this product? What' MOQ of it?
A: Yes welcome send sample order for test. MOQ is 1 piece.

Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks.

Q3: What' s the payment term
A: We usually use TT(Telegram Transfer) in advance, Western Union. Other payment method is negotiable.

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5: What' s the freight of it?
A: It depends on the order quantity. We have some reliable ship forwarders. We will offer cost effective method for you.

Q6: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty according to different products.

Q7: What action will you take if there are some product problems?
A: If there are defective ones in the batch of products, we will offer spare ones for.
