• Model NO.：H07RN-F
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE, TUV
• Brand：Fengda
• Colour：Red,Green,Blue,Black,White,as Request
• Flame Test：Yes
• OEM/ODM：Accepted
• Core：Single Core and Multicore
• Factory Type：Manufacturer
• Transport Package：Rolls or According to Cusotmers′ Reques
• Specification：1 to 400mm2
• Trademark：Fengda
• Origin：Tianjin, China(Mainland)

Application
H07rn-F cable has high flexibility, weather resistance, oil resistance, and friction resistance. It can be used in construction sites, stage and audio-visual equipment, port areas and dams. It is also suitable for temporary buildings and houses, drainage and sewage treatment, cold environments and harsh industrial environments.


What Is H07rn-F Cable?

H07RN-F cable is a heavy-duty rubber flexible cable rated at 450/750 V. H07RN-F rubber cable is manufactured with a conductive copper core, ethylene-propylene rubber (EPR) insulation and a polychloroprene (PCP) outer sheath. As a result, it is highly flexible, waterproof, oil-resistant, friction resistant, high tensile strength, and UV resistant. H07RN-F cable is suitable for applications such as handling equipment, mobile power, construction sites, port areas, and dams. Finally, H07rn-f neoprene cable conductors are considered heavy duty and flame retardant, making them suitable for use in harsh industrial environments. The most important cables have a long service time.

What Is The Meaning Of H07RN-F?

The definition of H07RN-F is a harmonized code according to the Grade of the European Committee for Electrotechnical Standardisation (CENELEC) to provide a standardized specification for electrical leads:

N - Relates to the PCP outer sheath
R - Refers to the EPR insulation
F - flexible copper conductors inside 07 - identifies the voltage rating as 450/750V
H - means conformity to harmonized standards

H07rn-F Cable Specification

H07RN-F rubber cable can be single-core or multi-core.
Typically, single-core wires are used for higher current ratings because one core is used for each of the three phases plus neutral and earth. Multi-core wires are available in 2-core, 3-core, 4-core or 5-core. However, some manufacturers offer rubberized flexible cable variants of up to 19 cores. H07RN-F wire is suitable for mobile equipment, appliances and building installations.

Neoprene Sheath
These copper wires use a rough rubber sheath made of neoprene (chloroprene), often called PCP. This material provides enhanced abrasion resistance and is resistant to many oils and compounds. As a result, neoprene-sheathed H07RN-F cables can still be used in harsh environments. And the performance of the cable is also particularly stable.

H07rn-F Cable Cores Colours

2 cores: Blue, Brown,

3 Cores: Blue, Brown, Yellow-Green

4 Cores: Black, Brown, Grey, Yellow-Green

5 Cores: Black, Brown, Grey, Blue, Yellow-Green

H07rn F Cable Prices

H07rn-F cables have many different sizes such as h07rn f 3 core cable, h07rn f 5g2 5, h07rn f 5g6 etc. The price for each size is different. You can contact FEIYA Cable to get your best price.

The H07RN-F cable is highly flexible and can be used in harsh weather, so this is why many customers purchase it. As a manufacturer, we make sure that our cables are qualified products. We can also provide samples for testing. Contact us and let's win more market together.
